Tektronix Tds3054 500mhz Scope, 5gs/s, 4-ch Tds3trg +tds3fft Gpib W/ 4 Probes

US $1900

Chicago, Illinois, United States
Jun 23rd

Open on mobile:
QR code

Fully working and calibrated. In addition, we will re-calibrate the unit at our accredited lab prior to shipping and include your company information on calibration certificate . See stancal.com for our capabilities If you require calibration data, calibration with data charge will be added, otherwise you will receive a calibration certificate free of charge ($345 value). Warranty: 14 Day ROR Includes : DS3TRG - Advanced Trigger Module TDS3FFT - FFT Module GPIB RS-232 Module 4 NEW probes From Mfr. Specifications: Features & Benefits 500 MHz Bandwidth Sample Rates up to 5 GS/s 4 Channels Full VGA Color LCD on all Models Built-in Floppy Disk Drive For Easy Storage and Documentation 21 Automatic Measurements Centronics Port Standard on all Models for Quick, Convenient Hardcopies 9-bit Vertical Resolution Multi-Language User Interface QuickMenu User Interface Mode for Quick, Easy Operation Advanced Triggers, such as, Glitch, Width, and Logic Standard on 4 Channel Models Telecommunications Mask Testing (TMT) Fast Fourier Transform (FFT) for Frequency and Harmonic Analysis Standard on 4 Channel Models Extended Video Application Module Support for Active Probes, Differential Probes, and Current Probes that Provide Automatic Scaling and Units Applications Telecommunications Manufacturing (Telecom Mask Test Application Module for Pass/Fail Compliance of ITU-T G.703 and ANSI T1.102 [Up to STS-1 Rates] Standards) Digital Design and Debug Video Design and Service (Video Application Modules Offer Line Count, HDTV and Custom Video Trigger, Video Display Graticules, SDI to Analog Video Conversion with Composite and Component Outputs, Video Picture Identification and Vectorscope) Industrial Electronic Design Power Supply Design Connected Instrumentation (10Base-T LAN, GPIB and VGA Modules with RS-232) Highly Mobile Environments (Optional Battery Pack for Convenient Use in the Field or Away from the Bench) The TDS3000 Series of Digital Phosphor Oscilloscopes The TDS3000 oscilloscopes are the lowest priced, most portable Digital Phosphor Oscilloscopes (DPOs). Now every design engineer and technician can take advantage of the tremendous benefits of DPOs. DPOs deliver a new level of insight that makes dealing with complex signals simple. DPOs display, store, and analyze, in real-time three dimensions of signal information: amplitude, time, and distribution of amplitude over time. Benefits of DPO DPOs have an intensity graded color display that provides information about the frequency of occurrence of signal amplitudes and widths. This helps the user locate and characterize waveform anomalies that can be elusive on traditional Digital Storage Oscilloscopes. The fast update rate of DPOs also makes it easier to capture and display infrequent waveforms or waveform variations. TDS3FFT - FFT Module When this module is installed in the TDS3000 Series scope, the scope becomes an excellent troubleshooting aid for: Testing impulse response of filters and systems Measuring harmonic content and distortions in systems Identifying and locating noise and interference sources Analyzing vibration Analyzing harmonics in 50 and 60 Hz power lines The TDS3FFT application module provides the following features: FFT Windows; Four FFT windows (Rectangular, Hamming, Hanning and Blackman-Harris) let you match the optimum window to the signal you are analyzing Analyze repetitive, single-shot and stored waveforms: An FFT waveform on any actively-acquired signal, last acquired signal or signal stored in the reference memory can be displayed The FFT vertical graticule can be set to either dB or linear RMS The time signals and FFT waveforms can be shown on the display at the same time. This helps in the quick analysis of circuit or system problems. DS3TRG - Advanced Trigger Module When this module is installed in the TDS3000 Series scope, an advanced trigger menu is added to the scope with the appropriate logic and pulse triggering capability.
