Tft Lcd Gm328 Transistor Tester, Diode Lcr Esr Meter,pwm,square Wave Generator

US $17.47

suzhou, China
Jul 23rd

Open on mobile:
QR code

Product Description Product description: 100% brand new and high quality Made of high-quality materials, durable The one-chip computer uses ATMEAG328P DIP-28. With IC holder The display unit adopts 160x128 pixel color display, full-screen characters 8x20, 16-bit color depth, graphic display element symbols Rotary switch control, one-key measurement, automatic shutdown Use 9V laminated battery, you can also use power adapter (DC 6.8-12V), the current of the whole machine is about 30mA, and the current after shutdown is about 20nA Automatic detection of NPN and PNP transistors, field effect transistors, diodes, double diodes, thyristors, thyristors, and automatic identification of transistor lead wires Test NPN and PNP transistor common emitter current amplification factor, base-emitter threshold voltage, turn-off collector-emitter leakage current Pole-pass transistor base-emitter threshold voltage and high current gain identification Darlington transistor Built-in detection power transistor and FET protection diode Test FET gate-source threshold voltage conduction, drain-source conduction resistance, gate-source capacitance At most two measuring resistances, so you can measure the three-pin adjustable resistance. If you adjust the adjustable resistance to the end, it can only be one measured resistance value. The maximum resolution of resistance measurement is 0.01. Can measure up to 50M Capacitance measurement range 25pF-100mF, resolution 1pF Measure the equivalent series resistance (ESR) of capacitors greater than 90nF at the same time. The maximum resolution of the equivalent series resistance is 0.01 Capacitors larger than 5000pF also show the rate of decrease after charging, and the capacitance value can reflect the quality factor (Q value) Measure up to two diodes to show their positive and negative, on-state voltage The LED also displays a graphic symbol diode, which has a much higher turn-on voltage than ordinary diodes. Reverse breakdown voltage lower than 4.5V can be detected by Zener diode, which is shown as a double diode symbol. The positive and negative voltages are subject to the diode symbol of about 700mV, and the voltage corresponding to the second diode symbol is turned on and adjusted. So don’t measure an ordinary diode and a Zener diode at the same time Test a single diode, and the PN junction capacitance between the test reverse junction and the reverse junction capacitance between the PN junction capacitance of the transistor under test can only enter the base and emitter, base and collector of the transistor at the same time. To test the capacitance of less than 25pF, you need to prepare a 30pF capacitor during the test, and then test the 30pF capacitor. After the test, connect the capacitors in parallel and measure again, and subtract the measured result from the measured value of the 30pF capacitor. For the following 2100 resistors, measure their inductance at the same time. The measurement range is from 0.01mH-20H About two seconds during the test, large capacitance and inductance will take longer Additional functions include frequency measurement, voltage measurement, square wave generator, PWM Generator, color selection, debugging and calibration, continuous testing and other functions The frequency range is from 1Hz to 1MHz or higher, measured at a frequency below 25kHz, and the display cycle resolution is up to 0.001mHz DC voltage measurement up to 50V One square wave signal output, multiple frequencies to choose from, the maximum output frequency is 2MHz Output a fixed frequency, variable duty cycle pulse signal (PWM), the duty cycle is adjustable from 1% to 99% capacitance function test, the test mode of continuous measurement of 2uF-50mF capacitance can be directly measured in its circuit (the measured capacitance needs to be energized in the circuit, and the measured capacitance needs to be fully discharged) Thyristors and thyristors can only identify their lead wires. It is also necessary to test whether the trigger current of the thyristor or thyristor is less than the current that the tester can provide. The tester can only provide a maximum of 6mA trigger current 1. Turn off 2. Transistor test 3. Frequency test 4. f-generator 5. 10-bit pulse width modulation 6. C+ESR@TP1:3 7. Continuous measurement of resistance 8. 1-||-3 Continuous measurement of capacitance 9. Rotary encoder 10. Self-check 11. Voltage test 12.FrontColor 13. Background color adjustment 14. Display date Package list: (optional) Case only: 1 *Acrylic case kit DIY kit: 1 *Un-welded tester component kit Assembly tester: 1 * Finished product tester Note: 1.The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor ad light brightness. 2.Please allow slight manual measurement deviation for the data. Payment We accept payment via Paypal only. Payment must be completed within 5 days. If you have any problems about payment, please contact us via ebay message. Delivery details We only ship to confirmed Paypal addresses. Please comfirm that your paypal address is in line with your shipping address. Please kindly note that the combined shipping is not provided because the shipping fee is calculated by weight. Also, the each additional item means exactly the the same color and size. It takes about 7-15 working days to US; about 10-30 working days to other countries. Transit time may be a little delayed because of the bad weather and customs inspection. If you do not receive your item within 30 working days since payment finished, please contact us immediately for further assistance. Contact us We strive for 100% customer satisfaction! Positive Feedback is very important to us. If you have any questions, please feel free to contact us via "Ask seller a question" . We will reply your email within 24 working hours.
