This is a listing for a Thermo 860-1050 Masterflex I/P Precision Brushless Drive Remote I/O, 33-650 RPM, Thermo 960-0000 Head What you will get: Thermo 860-1050 Masterflex I/P Precision Brushless Drive Remote I/O, 33-650 RPM Thermo 960-0000 Pump Head (From what I can find on the Cole Parmer site, this is a 77600-62 Pump Head.) Power Cord Manual for the Pump Manual for the Pump Head Description: This is a Thermo 860-1050 Masterflex I/P Precision Brushless Drive Remote I/O, 33-650 RPM. A Thermo 960-0000 (From what I can tell, this is a Cole Parmer 776000-62 Head) pump head is included with this unit. This is my item 8839. About the Thermo 860-1050 Masterflex I/P Precision Brushless Drive Remote I/O, 33-650 RPM I/P Standard Process Pump Product Benefits Brushless motor handles challenging applications with minimal maintenance. Non-chip epoxy-coated, washdown IP55-rated steel enclosure protects against moisture, chemicals, and dust. Speed control via three-turn potentiometer for quick, easy adjustments. Speed is displayed on an easy-to-read LED display from 0 to 100% of full speed, with 1% resolution. Remote outputs: “pump ready” signal and 4 to 20 mA outputs (requires 77300-32 remote cable kit). 1.8 m (6 ft) line cord with IEC 320/CEE 22 socket. Industrial Process Pump: Reversible, maintenance-free brushless motor with precise PWM control via a digital signal processor (DSP). Digital display of flow rate, dispense volume/cumulative amount per dispense, copy, and motor rpm. Calibrate in system for accurate flow rate display. Keypad lock feature prevents accidents or tampering. Remote control of flow speed (4 to 20 mA), direction, on/off, and tachometer output. 1.8 m (6 ft) line cord with IEC 320/CEE 22 socket. 860-1050 SPECIFICATIONS : Output Speed 33 to 650 rpm Torque output, Maximum Continuous 540 oz-in (39 kg-cm) 380 oz-in (27 kg-cm) @ 40°C Ambient Start-up 960 oz-in (69 kg-cm) Speed regulation Line ±0.25% F.S. Load ±0.25% F.S. Drift ±0.25% F.S. Display Three-digit, seven-segment LED Remote outputs (Model 860-1050 only) Current speed output (4–20 mA @ 0–600 ?) Pump ready output (N.O. & N.C. contact closure, 1A @ 28V AC/DC) Input Supply voltage limits Universal Input - 90 to 260 Vrms @ 50/60 Hz, Single Phase Current, max. 4.5A @ 115 Vrms, or 2.6A @ 230 Vrms Remote Inputs (Model 860-1050 only) External CW/CCW (Contact closure) Voltage input (0–10V DC @ 10 k?) Current input (4–20 mA @ 250 ?) Construction Dimensions (L x W x H): 14.0? x 10? x 9.1? (35 cm x 25 cm x 23 cm) Weight: 22 lb (10 kg) Enclosure Rating: IP55 per IEC 60529 Environment Temperature, Operating: 0 to 40°C (32 to 104°F) Temperature, Storage: –25 to 65°C (–13° to 149°F) Humidity (non-condensing): 10 to 100% Altitude: Less than 2000 m Pollution Degree: Pollution Degree 3 (Indoor use—sheltered locations) Chemical Resistance: Enclosure is painted steel Compliance: UL508C, CSA C22.2, No. 14 (For CE Mark): EN61010-1 (EU Low Voltage Directive) and EN61326 (EU EMC Directive) Description and Specs for the Thermo 960-0000 (AKA The Cole Parmer 77600-62 Pump Head) Highest flow rates, best pressure and suction performance of any I/P pump head Polyester and stainless steel (SS) construction withstands tough process environments Versatile mounting configurations—mount with tubing exiting to the top or side for flexible setup C-shaped design allows tubing to enter and exit the same side of the pump head—facilitates connection to tubing inlet and outlet Adjustable tubing retention; adjust to prevent tubing movement in head Ideal for industrial process and production applications requiring a single pump head, this heavy-duty three-roller pump head produces flow rates up to 19 LPM—the highest of any I/P pump head. Simple to load, it accepts Masterflex I/P high-performance precision pump tubing for greater pressure generation and suction lift, enhanced ability to pump viscous fluids, and longer tubing life. Adjustable tubing retention holds tubing securely in place and prevents movement while in the head. The I/P High-Performance pump heads are compatible with I/P drives that accept two or more pump heads. Drives that accept two heads have enough torque to run pump head even under difficult conditions such as high back pressure. Note: High-Performance pump head is not stackable. Masterflex Pump Head number Pump Material Occlusion Shaft Length I/P® Tubing 960-0000 PE/SS Fixed Short I/P ® 70, 88, 89 Typical Flow, Pressure and Vacuum Data, (CW Direction): I/P ® Tubing Flow rate Discharge Pressure* Vacuum* @ 650 rpm in (mm) Hg Suction Lift* @ 650 rpm ft (m) H20 @20 rpm L/min @ 650 rpm L/min Continuous psig (bar) Intermittent psig (bar) I/P ® 70 .26 8 25 (1.7) 40 (2.7) 26 (660) 29 (8.8) I/P ® 88 .40 13 20 (1.4) 35 (2.4) 26 (660) 29 (8.8) I/P ® 89 .52 17 15 (1.0) 20 (1.4) 24 (610) 27 (8.3) Number of rollers: 3 Occlusion: Fixed Maximum pump speed (rpm): 650 Nominal torque load-running: up to 600 oz-in (43 kg-cm) Housing materials: Stainless steel (SS), polyester (PE) body and tubing bed, polypropylene (PP) knob Roller/bearing materials: Stainless Steel (SS)/Sealed Stainless Steel Rotor materials: Stainless Steel (SS) Operating Temperature‡ : 32°F to 104°F (0°C to 40°C) Storage Temperature: -40°F to 149°F (-40°C to 65°C) Humidity: 5% to 95% (non-condensing) Dimensions (W x H x D): Operating: 7.5 in x 7.0 in x 6.0 in (191 mm x 178 mm x 152 mm) Open: 8.7 in x 7.0 in x 10.0 in (221 mm x 178 mm x 254 mm) Weight: 8 lb (3.63 kg) Links and Documentation: Thermo Fisher Scientific 860-1050 Masterflex I/P Precision Brushless Drive Remote I/O, 33-650 RPM Manual for the 77600-62 Pump Head This ships free in the USA. If you receive your item and it is not to your 100 Percent Satisfaction, please contact us before leaving feedback. I strive to make sure every transaction is a positive one! I wanted to reach out and let you know that eBay is changing the way Sellers are rated. I am not overjoyed with what's happening, but I have to roll with it. IF you have a problem with my item, I would like you to use the "Contact Seller" link in the listing, or call me. Please don't open a case. Cases count against me even if they are resolved. I stand behind my items and will work out any problems that you may have with an item. So please contact me if you have a problem with an item I have sold you and don't use the eBay Case as a means of communication. International Buyers, Please Note: Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. Please check with your country's customs office to determine what these additional costs will be prior to bidding/buying. These charges are normally collected by the delivering freight (shipping) company or when you pick the item up do not confuse them for additional shipping charges. We do not mark merchandise values below value or mark items as "gifts". US and International government regulations prohibit such behavior. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
