Ti Cc2564 Sh-h4 Bt4.0 Dual Mode Module Supports Spp, Ble Profiles For Arduino

US $9.90

??, ???, China
Jun 9th

Open on mobile:
QR code

1,Overview SH-H4 is a fully integrated Bluetooth module that complies with Bluetooth 4.0 dual mode protocols(BR/EDR/BLE).It uses TI CC2564 bluetooth chip. It provides several interfaces such as UART, I2C, PCM, AIO, PIO, etc., which can customized different applications.SH-H4 supports SPP, BLE profiles. It integrates MCU, Baseband controller, RF, etc. in a small package, so the designers can have better flexibilities for the product shapes.SH-H4 can be controlled by UART port or other interfaces. Please refer to software design guide for the interfacing protocol. 2,Feature Fully qualified Bluetooth 4.0/3.0/2.1/2.0/1.2/1.1 Postage stamp sized form factor, 13mm x 27mm x 2mm Low power Class 1.5 support(high output power) The default UART Baud rate is 115.2Kbps and can support from 1200bps up to 921Kbps,. UART, I2C , PCM data connection interfaces. Embedded Bluetooth stack profiles support(requires no host stack): SPP, HFP/HSP, A2DP, AVRCP, MAP, and all BLE protocols. 3,Images VCC: input power supply 3.3~6V, Prohibit more than 7V GND: Ground TX: transport RX: receive State: when bluetooth is connected , output "High level", "no conntected" output "low level" en:when module is connected, give a high level to "EN",the module will disconnected. 4.Application Fields Smart Watch and Bluetooth Bracelet Health & Medical devices Measurement and monitoring systems Industrial sensors and controls Asset tacking 5,GENERAL SPECIFICATION 6,Application Circuit Diagram 7,AT Command The way to the AT command mode: supply power to the module, it will enter to the AT mode if it needn’t pair. The interval of command is about 1 second. Default parameter: Baud rate:9600N81 Format: AT+Command[=Parameter]<CR><LF> Description: Command always start with AT+ and end with <CR><LF>. <CR> means "carriage return" and corresponds to the hexadecimal value 0x0D. <LF> means "line feed" and corresponds to the hexadecimal value 0x0A. Parameter between [ ] may not exist. Parameter always start with =if exist. Example : AT+BDNAME=? <CR><LF> :Query current device's name. AT+BDPIN=8888 <CR><LF> :Modify current device's pin code to '8888'. Command 1 , Testing Connection Commands Command Answer Parameter AT OK None Command 2 , Query/Set —— Bluetooth Name Command Answer Parameter Query:AT+BDNAME=? +BDNAME=[para1] Para1:the name of device Default:SH-H4 Set:AT+BDNAME= [para1] +BDNAME=[para1] Example: Send: AT+BDNAME=? Return: +BDNAME=SH-H4 Send: AT+BDNAME=ABC Return : +BDNAME=ABC Command 3, Query module bluetooth address Command Answer Parameter AT+BDADDR=? +BDADDR=[MAC] MAC: Bluetooth address Command 4 , Query/Set —— Baud Rate Command Answer Parameter Query:AT+BDBAUD=? +BDBAUD=[para1] Para1: 9600 38400 115200 Set:AT+BDBAUD =[para1] +BDBAUD=[para1] Query device baudrate Send:AT+BDBAUD=? Return: +BDBAUD=9600 Modify device baudrate Send:AT+BDBAUD=115200 Return: +BDBAUD=115200 Command 5 , Query/Set ——PIN Code Command Answer Parameter Query:AT+BDPIN=? +BDPIN=[para1] Para1 is PIN Code: Default:0000 Set:AT+BDPIN= [para1] +BDPIN=[para1] e.g. Query Pin Code Send: AT+BDPIN=? Return: +BDPIN=0000 Setup Pin Code 1234 Send: AT+BDPIN=1234 Return : +BDPIN=1234

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	General
support ios ble	yes
Model	SH-H4 bluetooth module
support android spp	yes
Country/Region of Manufacture	China
Compatibility	bluetooth 4.0,3.0,2.1,1.1
bluetooth version	4.0
