Tilt Switch Sensor Brick

AU $1.90

Sydney, Australia
Jun 9th

Open on mobile:
QR code

Overview Tilt switch sensor in electronic brick form can be connected to I/O port and used in tilt sensing for car or robot. It produces a low when the sensor is rotated to form an angle of more than 15Â° with the horizontal line. DESCRIPTION What is an electronic brick? An electronic brick is an electronic module which can be assembled like Lego bricks simply by plugging in and pulling out. Compared to traditional universal boards and circuit modules assembled with various electronic components, electronic brick has standardized interfaces, plug and play, simplifying construction of prototype circuit on one’s own. There are many types of electronic bricks, and we provide more than twenty types with different functions including buttons, sensors, Bluetooth modules, etc, whose functions cover from sensor to motor drive, from Ethernet to wireless communication via Bluetooth, and so on. We will continue to add more types to meet the various needs of different projects. Electronic brick of tilt switch can be connected to analog I/O port and used in tilt sensor for smart car or robot. When the sensor is in the horizontal position, the output is high level; when the sensor rotates counterclockwise to form an angle of more than 15° with the horizontal line, the output is low level. Features 1. Plug and play, easy to use. Compatible with the mainstream 2.54 interfaces and 4-Pin Grove interfaces in the market. 2. With use of M4 standard fixed holes, compatible with M4-standard kits such as Lego and Makeblock. Specifications PCB size 24.0mm X 21.0mm X 1.6mm Working voltage 3.3 or 5V DC Operating voltage 3.3 or 5V DC Compatible interfaces 2.54 3-pin interface and 4-pin Grove interface(1) Electrical characteristics Parameter Min. Typical Max. Unit Working voltage 3 5 5.5 VDC Digital output voltage (VCC=5V) 0 - 5 V Working current (VCC=5V) - 450 - uA DEMO Connect S port of electronic brick of tilt switch to D2 port of Arduino board, and we will use the following program to read its digital value. When the digital value read is high level, LED lamp will be ON; when the digital value read is low level, LED lamp will be OFF. int tilt=2; //connect tilt to D2 int LED=13; void setup() { pinMode(LED, OUTPUT); pinMode(tilt, INPUT); } void loop() { if(digitalRead(tilt)==HIGH) //when the digital output value of tilt is high, turn on the LED. { digitalWrite(LED, HIGH); } if(digitalRead(tilt)==LOW) //when the digital output value of tilt is low, turn off the LED. { digitalWrite(LED, LOW); } } Revision record Version Description Date Written by v1.0 Initial edition 17th, April, 2013 Stan Lee Specification Brick Type Sensor Brick Brick Interface 3PIN Brick Power Supply 5V Board Size 24 x 21 x 1.6mm LED Color No Weight 15.00g Model IM120710019 Download Schematic SCH_IM120710019 Datasheet DS_IM120710019 Demo Code DEMO_IM120710019

Condition:	New	Brand	IteadStudio
Model	IM120710019
