Udb1005s Function Signal Generator With 60mhz Frequency Counter Dds Module 5mh

US $46.99

China, China
Jan 29th

Open on mobile:
QR code

WELCOME TO MY SHOP MADE WHOLESALES !!! In UDB100x(S) series,we have eight moels as following: 1.UDB1002 2MHz 2.UDB1002S 2MHz with frequency sweep functon 3.UDB1003 3MHz 4.UDB1003S 3MHz with frequency sweep functon 5.UDB1005 5MHz 6.UDB1005S 5MHz with frequency sweep functon 7.UDB1008 8MHz 8.UDB1008S 8MHz with frequency sweep functon This product is UDB1005S 5MHz with frequency sweep function. Introduction of the instrument UDB100x(UDB100xS) series direct digital synthesis signal generator use DDS technology and FPGA design with the characters of high stability and low distortion ect., with the function of TTL output and 60MHz frequency meter, UDB100xS series have sweep function, the start and end frequency and sweep time can be set at will. It's the ideal equipment of electronic engineer, laboratory, production lines, the teaching and scientific research. Main technology data 1.Signal Output function Output amplitude >=9Vp-p (signal output,no load)(MAX) About 0.1Vp-p(MIN) Output impedance 50 omega +/-10%(signal output) DC offset +/-2.5V(no load) Display LCD1602 Frequency range 0.01Hz - 2MHz(UDB1002) 0.01Hz - 3MHz(UDB1003) 0.01Hz - 5MHz(UDB1005) 0.01Hz - 8MHz(UDB1008) Resolution 0.01Hz(10mHz) Frequency Stability +/-1x10-6 Frequency accuracy +/-5x0-6 Sine wave distortion <=0.8%(reference frequency is 1kHz) Trinagle linearity >=98%(0.01Hz-10kHz) Rise and fall time of square wave <=100ns Square Wave Duty range 1%-99%(digital control mode) 2.TTL Output function Frequency range 0.01Hz - 2MHz(UDB1002 or UDB1002S) 0.01Hz - 3MHz(UDB1003 or UDB1003S) 0.01Hz - 5MHz(UDB1005 or UDB1005S) 0.01Hz - 8MHz(UDB1008 or UDB1008S) Amplitude >3Vp-p Fan Out >20 TTL loads 3.COUNTER function Counter Range 0-4294967295 Frequency Meter Range 1Hz-60MHz Input Voltage Range 0.5Vp-p -20Vp-p 4.SWEEP function(as for UDB100xS series) Frequency range fM1 to fM2 Sweep time 1s-99s 5.Others function Save and Load Parameter M0-M9(M0:default load) Contact Us Please contact us via TM, Email OR leave message Please don't hesitate to contact us if you have any questions and idea Goods Return/Refund 1 All of our products have been checked and packaged in a good condition before post out 2 Please note that men made defects are not guaranteed, such as damage after incorrect use and so on 3 If you wish to exchange defective items, please note the following steps 4 Step 1) Contact us within 3 days after received the goods 5 Step 2) Send photos OR video to us to show the problem of the items 6 Step 3) Return the items within 3 days with tracking number after contacted us 7 Buyer should pay the shipping fees incurred for exchange 8 The items returned should be kept in their original status 9 We accept all reasonable refunds such as out of stock after payment, but not recommend 10 All customers should contact us for seeking a better solution before asking refund Feedback 1 Positive feedback "5-Star" is very important to us, we sincerely invite you to leave Positive Feedback “5-Star” if you are satisfied with our product and service 2 Please contact us before leaving any Neutral (3 Stars) or Negative (1-2 Stars) feedbacks. 3 We will try our best to work with you to solve the problem 4 We will leave a "5-Star" feedback for all customers after confirmed payment Shipping · We Ship to Worldwide, United States ,Canada,United Kingdom ,France,Australia we will used E-packed ship ,arrived about 10~15 days · Items will be shipped within 2 business day on payment received. · Items are shipped from China using Airmail, reach most of the countries within 10 to 30 business days. · Delivery time depends on destination and other factors, it may takes up to 50 business days. THANK YOU !

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	1005S
Country/Region of Manufacture	China
