Uni-t Ut203 Digital Clamp Meter

US $56.00

HK, Hong Kong
Jan 29th

Open on mobile:
QR code

Digital clamp meter UNI-T UT203 is a reliable and low consumption clamp multimeter. Digital clamp meter UNI-T UT203 measures AC/DC voltage and current, resistance, frequency, duty cycle, also performing diode check and continuity test. This clamp meter has overload protection. Digital Clamp Meter UNI-T UT203 Features Measuring functions: AC/DC voltage AC/DC current Resistance Temperature Diode check Continuity test Duty cycle Auto ranging Data hold function Display "REL" mode Sleep mode Low battery display 28 mm maximum jaw diameter Measurement update speed 3 times/second Compact and comfortable design Compliance with safety requirements IEC 61010 CAT II 600 V, CAT III 300 V Digital Clamp Meter UNI-T UT203 and UT207A Comparative Specifications Model UT203 UT207A Display LED, max. 3999 digits 36 x 18 mm LED, max. 3999 digits 47 x 30 mm DC voltage Range 400 mV / 4 V / 40 V / 400 V / 600 V 400 mV / 4 V / 40 V / 400 V / 1000 V Accuracy ±(0.8%+1) Input impedance 10 M? Overload protection 600 V rms DC 1000 V / AC 750 V rms AC voltage Range 4 V / 40 V / 400 V / 600 V 400 mV / 4 V / 40 V / 400 V / 750 V Accuracy ±(1%+5) ±(1.2%+3) Input impedance 10 M? Overload protection 600 V rms DC 1000 V / AC 750 V rms DC current Range 40 A / 400 A 40 A / 400 A / 1000 A Accuracy ±(2%+3) ±(1.5%+5) Overload protection 400 A DC/AC 1000 A DC/AC AC current Range 40 A / 400 A 40 A / 400 A / 1000 A Accuracy ±(2.5%+5) ±(2%+2) Overload protection 400 A DC/AC 1000 A DC/AC Resistance Range 400 ? / 4 k? / 40 k? / 400 k? / 4 M? / 40 M? Accuracy ±(1%+2) Duty cycle 0.1%~99.9% Frequency Range 10 Hz / 100 Hz / 1 kHz / 10 kHz / 1 MHz 10 Hz / 100 Hz / 1 kHz / 10 kHz / 1 MHz / 10 MHz Accuracy ±(0.1%+3) Temperature – -40?C ~ 1000?C Capacitance – 4 nF / 40 nF / 400 nF / 4 µF / 40 µF / 100 µF Power supply 6F22 battery (9 V) Dimensions, mm 208 x 76 x 30 285.3 x 105 x 44.5 Weight, g 260 533 Digital Clamp Meter UNI-T UT203 Package Clamp meter UNI-T UT203 (1 pc.) Test lead (1 pair) Carrying case (1 pc.) Batteries (NEDA1604, 6F22 or 006P) (1 pc.) User manual (1 pc.)

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	UNI-T
Capacitance	does not measure the capacitance
Model	UTM 1203 (UT203)
Frequency	up to 1 MHz
Country/Region of Manufacture	China
DC	up to 400 A
Warranty	24
AC	up to 400 A
Jaw diameter	diameter 28 mm
Temperature	no
DC Voltage	up to 600 V
Power	no
AC Voltage	up to 600 V
Duty cycle	yes
Resistance	up to 40 MOhm
