Uni-t Ut231 Digital Clamp Meter

US $139.00

HK, Hong Kong
Jan 29th

Open on mobile:
QR code

The digital clamp meter UNI-T UT231 is a power meter measuring not only AC voltage and current but also active, apparent and reactive power. The UNI-T UT231 clamp meter measures temperature, frequency, active energy and can be connected to PC. Digital Clamp Meter UNI-T UT231 Features Measuring functions: AC voltage AC current Active and full power Reactive power Power factor Phase angle Active energy Frequency Temperature Auto ranging True RMS Maximum and minimum data hold Single-phase 2-wire measurements Calibration function Data hold function Sleep mode Low battery display Display backlight USB connection 55 mm maximum jaw diameter Measurement update speed 3 times/second Compact and comfortable design Compliance with safety requirements IEC 61010 CAT III 600 V, CAT IV 300 V Digital Clamp Meter UNI-T UT231 Technical Specifications Display LED, max. 9999 digits 46 x 42 mm AC voltage Range 15 V / 100 V / 300 V / 600 V Accuracy ±(1.2%+5) Input impedance 10 M? Overload protection 600 V rms AC current Range 40 A / 100 A / 400 A / 1000 A Accuracy ±(2%+5) Overload protection 1000 A rms Active power Range up to 600 kW Accuracy ±(3%+5) Apparent power Range up to 600 kWA Accuracy ±(3%+5) Reactive power Range up to 600 kWAr Accuracy ±(4%+5) Power factor 0.3~1 (±0.02%±2) Phase angle 0?~360? Frequency 20 Hz – 500 Hz Active energy up to 9999 kWh Temperature -50?C~1000?C Power supply 4 batteries LR6 (1.5 V) Dimensions, mm 303 x 112 x 39 Weight, g 601 Digital Clamp Meter UNI-T UT231 Package Clamp meter UNI-T UT231 (1 pc.) Test lead (1 pc.) Alligator clip (1 pc.) Point contact temperature probe (1 pc.) USB interface cable (1 pc.) Software (1 pc.) Tool box (1 pc.) Batteries (LR6) (4 pcs.) User manual (1 pc.)

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	UNI-T
Capacitance	does not measure the capacitance
Model	UTM 1231 (UT231)
Frequency	up to 500 Hz
Country/Region of Manufacture	China
DC	does not measure the DC
Warranty	24
AC	up to 1000 A
Jaw diameter	diameter 55 mm
Temperature	yes
DC Voltage	does not measure the DC voltage
Power	yes
AC Voltage	up to 600 V
Duty cycle	no
Resistance	doesn't measure resistance
