Uni-t Ut61b Digital Multimeter

US $59.00

HK, Hong Kong
Jan 29th

Open on mobile:
QR code

UNI-T UT61B digital multimeter measures AC/DC current and voltage, resistance, capacitance, frequency, temperature (?C/?F), duty cycle, tests continuity and diodes. Please note that the standard temperature probe from the multimeter package contents allows measuring temperature up to 300 ?C. In case you require measuring temperatures above that value, please, buy Uni-T UT-T03 Temperature Probe. Features Functions: AC/DC current and voltage resistance capacitance frequency temperature (?C/?F) duty cycle continuity test (with buzzer) diode test Relative reference measurements Max/Min measurements Data Hold function Auto/Manual ranging Sleep mode RS232 interface Fuse Low battery indication Technical Specifications Display LCD with analog bargraph and backlight, 65 x 43 mm Range Accuracy DC voltage, V 40mV/400mV ±(0.8%+3) 4V/40V/400V ±(0.5%+1) 1000V ±(1%+3) AC voltage, V 40mV/400mV/750V ±(1.2%+5) 4V/40V/400V ±(1%+3) DC current, A 400µA/4000µA ±(1%+2) 40mA/400mA ±(1.2%+3) 4A/10A ±(1.5%+3) AC current, A 400µA/4000µA ±(1.2%+5) 40mA/400mA ±(1.5%+5) 4A/10A ±(2%+5) Resistance, ? 400?/4M? ±(1.2%+2) 4k?/40k?/400k? ±(1%+2) 40M? ±(1.5%+2) Capacitance, F 40nF/400nF/4µF/40µF ±(3%+5) 400µF4000µF ±(4%+5) Frequency, Hz 10Hz-10MHz ±(0.1%+4) Temperature, ?C -40?C~-20?C ±(8%+5) -20?C~0?C ±(1.2%+4) 0?C~100?C ±(1.2%+3) 100?C~1000?C ±(2.5%+2) Temperature, ?F -40?F~-4?F ±(8%+6) -4?F~32?F ±(1.2%+5) 32?F~212?F ±(1.2%+4) 212?F~1832?F ±(2.5%+3) Duty cycle 0.1%~99.9% Power 9V battery: NEDA 1604, 6F22 or 006P Dimensions (H x W x D), mm 180 x 87 x 47 Weight, g 370 Package Contents Multimeter Uni-T UT61B – 1 pc. Test leads – 1 set K-type point contact temperature probe – 1 pc. Data cable RS-232 – 1 pc. Software – 1 pc. Battery – 1 pc. Manual – 1 pc.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	UNI-T
Frequency	up to 10 MHz
Model	UTM 161B (UT61B)
DC	up to 10 A
Country/Region of Manufacture	China
AC	up to 10 A
Warranty	24
Inductance	no
DC Voltage	up to 1000 V
Temperature	yes
AC Voltage	up to 750 V
Power	no
Resistance	up to 40 MOhm
Duty cycle	yes
Capacitance	up to 4000 ?F
