Overview Comprehensive guarantee for 2 years except the wearing parts Fast shipping from California Shipping out within 24 hours (from Monday to Friday) Model CPM-RS-720C Paper Feeding Mode Floor stand Driver Stepper motor Control Panel Over - head, LCD keyboard Maximum Paper Feed Width 720mm (28") Maximum Cutting Width 630mm (25") Maximum Cutting Speed 600mm (23") / s Maximum Cutting Length 2000mm (79") Maximum Cutting Thickness 0.1" (1.2mm) Knife Press 10-500g Minimum Size for Cutting Letters 3mm (0.1") Repetition Precision 0.01mm (0.0004") CPU RISC CPU Type of Tool Carbide blade Type of Plot Pen All types of plot pens with a 0.5"(12mm) diameter Plotting Instruction HPGL Interface USB2.0 RAM 4M Real cutter softball Yes Optical Function Yes Emergency stop Yes Power Supply AC90V-AC230V, 50Hz-60Hz Red optic sensor, register marks with "Cut" Support, cut plug-in for Corel DRAW. With such a fast, accurate and versatile vinyl cutter plotter, you can contour cut most any media pre - printed - from your choice of inkjet, solvent based and laser printer. WinPCSign plotting software (Match training CD) Support CorelDraw output directly (But you need to buy a soft dog), please choose CutMate2.3 CorelDraw driver with softdog This vinyl cutting plotter has a contour cutting function and is used to cut all kinds of pictures, letters, and similar materials on self-adhesive vinyl, sticker. It is made in China and comes with one year warranty.Please choose contour cut function, WinPCSign 2009 Basic Plotting Software. • Low cost and high performance machine for the manufacture of signaling. • Controlled by RISC high-speed processor, a high speed cache. • It can regulate the pressure and speed numerically at real-time. • It supports CorelDraw files, bringing great convenience to work. • The cutting plotter is highly stable and has nearly no malfunctions. • It has a stylish design and very solid support. • The cutting plotter has LCD with a very accurate and simple English Menu, operated it by pressing buttons. • The plotter’s pinch rollers are adjustable. • Unique soft impact cutter • This cutting plotter adopts the latest numerical technology, which creates a new concept of cutting. • It has a perfect output: there's no saw tooth even when using high speed. • It doesn't shake while cutting. • The paper stays in place when using rolls of media. • Save money for you. • Smooth cutting • It is very convenient and can be achieved fast. • The cutting plotter is easy to operate. 1.Protection of track 2.Carriage 3.Pinch roller 4.LCD monitor 5.Keyboard panel 6.LED lamp 7.Right shell 8.Machine’s foot 9.Knife holder 10.Seat of knife holder 11.Left shell 12.Handle to control the roller 13.AC power port 14.Safe fuse 15.Power switch 16.RS232 port Locknut holder's shell close screw blade On the working state, the knife can rotate in holder very smoothly. In the first time you can screw the "close screw" off the "holder's shell", set the blade into bottom of holder, then close the "close screw" to avoid the knife falling out, let the knife peep out of the holder less than 0.5mm. When you want to change the blade, take out the old blade, change a new one, then close the" close screw", keep the blade peep out of the holder less than 0.5mm. (The locknut will not screw, usually). Close screw Holder shell Plotting pen. You can use usual ball pen as plotting pen; keep the ball pen peep out of the holder between 4mm and 5mm. the other using method is similar as blade's process; please try it yourself according to the blade's changing method. Double spring press paper holder, not distortion Silica gel pinch roller, durable in use LCD display control panel CE mark and power supply USB interface The life of Blade The correct usage could prolong the life of blade. (1)The more length the blade sharp extends out, the shorter life blade will work. So you should avoid cut through the paper. (2)The more Force, the blade life will get short. (3)Trying to use small Force, when the blade edge is getting less sharp, you could add the working force suitable. (4)Different brand blades will have different life. (5)You should change the blade when you find the old one has no tartness, to avoid affecting the work badly. How to fix and setup the blade? Turn off the plotter power. Set the holder on holder's seat; close the screw of seat of holder. Turn on the power, the carriage will move to right side; you can press "TEST" key to examine the plotter. Remark: A. You should keep the blade clean and don’t break the blade sharp. B. The length out of the cover should be just a little bit, say 0.2mm around over the paper thickness which you will cut! On the working state, the knife can rotate in holder very smoothly. In the first time you can screw the "close screw" off the "holder's shell", set the blade into bottom of holder, then close the "close screw" to avoid the knife falling out, let the knife peep out of the holder less than 0.5mm. When you want to change the blade, take out the old blade, change a new one, then close the" close screw", keep the blade peep out of the holder less than 0.5mm. (The locknut will not screw, usually). How to load media? Steps: Load media / Load paper: When you move the roller, you must lift the handle first; the right roller will not move, usually. Lift the handle, the roller will lift 1 - 2mm, and then you can load your media. Laying down the handle, you can press "UP" key (S+) or "DOWN" key (S-) continuously, the paper will roll to front or back; please confirm the paper must move straightly during the distance that you want to cut. Adjust the speed and pressure, and then you can output the data to the plotter. Option Accessory The structure of floor stand: Details Pictures (Remark: The hop-pocket is optional accessory) Double spring press paper holder, not distortion Silica gel pinch roller, durable in use LCD display Control Panel CE mark and power supply USB interface 1.Details Show: 2.Function Show: The life of Cutting Knife Blade The correct usage could prolong the life of blade. (1)The more length the blade sharp extends out, the shorter life blade will work. So you should avoid cut through the paper. (2)The more Force, the blade life will get short. (3)Trying to use small Force, when the blade edge is getting less sharp, you could add the working force suitable. (4)Different brand blades will have different life. (5)You should change the blade when you find the old one has no tartness, to avoid affecting the work badly. How to fix and setup the cutting knife blade? Turn off the plotter power. Set the holder on holder's seat; close the screw of seat of holder. Turn on the power, the carriage will move to right side; you can press "TEST" key to examine the plotter. Remark: A. You should keep the blade clean and don’t break the blade sharp. B. The length out of the cover should be just a little bit, say 0.2mm around over the paper thickness which you will cut! On the working state, the knife can rotate in holder very smoothly. In the first time you can screw the "close screw" off the "holder's shell", set the blade into bottom of holder, then close the "close screw" to avoid the knife falling out, let the knife peep out of the holder less than 0.5mm. When you want to change the blade, take out the old blade, change a new one, then close the" close screw", keep the blade peep out of the holder less than 0.5mm. (The locknut will not screw, usually). How to load media? Steps: Load media / Load paper: When you move the roller, you must lift the handle first; the right roller will not move, usually. Lift the handle, the roller will lift 1 - 2mm, and then you can load your media. Laying down the handle, you can press "UP" key (S+) or "DOWN" key (S-) continuously, the paper will roll to front or back; please confirm the paper must move straightly during the distance that you want to cut. Adjust the speed and pressure, and then you can output the data to the plotter. Common Cutting Function Contour Cutting Function How to use this vinyl cutter to make personal T-shirts, sport clothes, uniform clothes, advertising shirts, color flags? How to use this vinyl cutting machine to make contour cutting for heat transfer? This 24" Redsail Vinyl Sign Cutter with Contour Cut Function is great for business usage; it is able to make any kind of design and it works faster and easier than other models. This machine can be used for Advertising production, Wall stickers, Post, Retro-reflective sheeting, Adhesive, Heat Transfer Film, Mobile phone sticker, CAD diagram, Dust cloth, banners, Display Board, Light boxstickers, glass decal, penaflex, vinyl decal, masking film for painting or etching, vinyl lettering, decorative scrapbook papers, card stock, stencils, magnetic sheets, etc. As well as all kinds of flexible heat transfer media like T-shirts, magic cut colored paper for garments, etc. Quality report: Terms & Condition of Purchase: After we receive PO from customer with stamp, we give PI for customer. Lead Time: After receiving customer's deposit, within 1 - 3 days. Box: There is total one carton box. Machine Dimension 60" x 9.4" x 8.7" (1520mm x 240mm x 220mm) Machine Weight 55lb (25kg) Package Carton box with foam fixed Packing Size 67" x 12" x 15" (1700mm x 310mm x 390mm) Gross Weight 59.4lb (27kg) Pictures Article Unit Quantity Cutting plotter set 1 WinPCSign basic 2009 version plotting software set 1 USB cable pc 1 Power cable pc 1 Cutting blades pc 3 Blade holder set 1 Pen holder set 1 User manual (CD) copy 1-3 Coat for the Plotter pc 1 Deluxe Aluminum Stand set 1 Screw for stand set 1 Packing List Standard Accessories 1. CPM-RS-C Vinyl Cutter 2. About WinPCsign software-FAQ 3. cutting plotter Trouble 4. RS Cutting Plotter installation of USB Port 5. RS series vinyl cutter user manual 6. User Manual for Winpcsign with Red dot Warranty Comprehensive guarantee for 2 years except the wearing parts 24 - hour technical support by email or calling User - friendly English manual for machine using and maintaining Spare Parts Supports We provide all replacement parts for all machines we sold, if you have a parts that break beyond warranty period, you could order it directly from us at reasonable prices. We would post the new parts with step by step instructions in PDF format on how to replace the parts to you. If you want to buy any parts from us, please tell us the names or pictures of the parts. Satisfaction Guarantee For the items other than consumable products sold via www.Sign-in-China.com, we provide 24 months warranty after delivery. All the extra parts for equipment can be purchased from www.Sign-in-China.com. We offer 14 days 100% satisfaction guarantee on all our machines. If you are not satisfied after receiving an item, Sign-in-China.com promises that, within 14 days after actual delivery of such an item, you are allowed to return the item to us and get complete refund, provided the returned item does not affect its subsequent re - selling and you also undertake the charge of returning delivery. More information, please look at the document of Training & Warranty & Service Policies. Shipping apps.froo.com | Froo www.froo.com | Froo Cross Sell, Free Cross Sell, Cross promote, eBay Marketing, eBay listing Apps, eBay Apps, eBay Application On Nov-10-16 at 19:49:17 PST, seller added the following information:
