Vc8145b Dual Display True Rms 4 2/3 Bench Multimeter Dca 0.05% Dcv 0.03% Usb

US $225.00

Shenzhen, China
Jan 29th

Open on mobile:
QR code

Features: 1. 33000 counts digital reading, high accuracy of 0.03% for DC voltage measurement. 2. Measure: DC voltage, AC voltage, DC current, AC current, resistance, frequency, continuity test, dBm and diode test; Max, Min, Average and Relative value. 3. Can measure 1000V high voltage, 10A current, 100M? resistance and 30MHz frequency. 4. Can communicate with PC through USB interface. 5. 0.05% accuracy for DC currenct can be used for measuring 4-20mA loop current. 6. AC True RMS measurement. 7. Measuring speed: high speed, 6-7 times/second; low speed, 3 times/second. Specifications: Basic function Range Accuracy Input impedance DC Voltage 300mV/3V/30V/300V/1000V ±(0.03%+5) AC Voltage 300mV/3V/30V/300V/750V ±(0.5%+50) DC Current 0.3mA/3mA/30mA/300mA/10A ±(0.05%+3) AC Current 30mA/300mA/10A ±(0.5%+30) Resistance 300?/3k?/30k?/300k?/3M?/30M?/100M ? ±(0.05%+3) Frequency 300Hz/3kHz/30kHz/300kHz/3MHz/30MHz ±(0.03%+2) CONTINUITY Range Continuous Resistance Open Circuit Voltage Short Circuit Current Max.input voltage 300? 150? 2.5V About 1.25mA 250VDC/RMSAC Diode test Range Accuracy Max.measuring current Max.measuring current Max.input voltage 3.0000V 1%

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	VC8145B
Country of Manufacture	China
MPN	VC8145B
