Vc97 3999 Lcd Digital Multimeter Auto Range & Bag R C F V A Meter;

US $31.60

  • Hong Kong, China
  • Jan 29th
Description VC97 3999 LCD Digital Multimeter Auto Range & bag R C F V A meter; Features: 1.New type holster, streamline design; 2.Large LCD makes the reading clearly; 3.Strong antimagnetic and anti-jamming performance; 4.Full function protection,; 5.Unit symbol display, very easy to reading; 6.Relative value, frequency/duty cycle measuring, data hold. Technical Basic functionRangeBasic accuracy DCV400mV/4V/40V/400V/1000V±(0.5%+4) ACV4V/40V/400V/1000V±(0.8%+6) DCA400uA/4000uA/40mA/400mA/20A±(1.0%+5) ACA400uA/4000uA/40mA/400mA/20A±(1.5%+5) Resistance400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ±(0.8%+1) Capacitance4nF/40nF/ 400nF/4uF/40uF/200uF±(3.5%+8) Frequency100Hz/1kHz/10kHz/100kHz/1MHz/30MHz±(0.5%+4) Centigrade temperature-40~1000℃±(0.8%+4) Special functionVC97 Diode test√ hFE test√ Continuity testApprox. less than 30Ω±10Ω Low battery indicationApprox less than 2.4V Duty cycle measuring√ Data hold√ Auto power offApprox.15minutes Function protect√ Input impendence10MΩ Sampling rate3times/s AC frequency response40-400Hz Operation wayManual or auto range Max. display4000 LCD size65x41mm Battery3V AAA×2 pcs ( not included) Power dissipationQuiescent current approx. 2mA Package Content: 1x VC 97 Digital Multimeter 1x User Manual 2x basic cable Preview Engineered for professional eBay sellers!
