Vc97 Multimeter Tester Thermometer Resistance Capacitance Ac Dc Ohm 4000count

US $440

Hong Kong, Hong Kong
Jan 29th

Open on mobile:
QR code

VC97 Multimeter Tester Thermometer Resistance Capacitance Frequency AC DC Ohm Description : The Professional Auto-range Digital Multimeter is a powerful tool for debugging circuits with high performance, high accuracy with large LCD display measuring DCV, ACV, DCA, ACA,Resistance, Capacitance, Frequency, Temperature, Duty Cycle Measurement, Triode,Diode and Continuity Test. Designed function includes: unit signal displaying, relative value measuring, AUTO/MANUAL range switch, auto power off and warning function, auto negative polarity indication, overload protection, etc. This multimeter is most suitable for use on production lines or lab, R & D, maintenance and repairing work. Features Designed for field professionals 3 3/4 digit Large LCD Display With stand, auto-off and buzzer Low battery display indication Automatic negative polarity indication Manual and automatic ranging Temperature measurements (-40~1000°C) Full overload protection Perform test like DCV, ACV, DCA, ACA, Resistance, Capacitance, Frequency, Temperature,hFE, Duty Cycle, Triode, Diode and Continuity Test Hard sealed IC Ergonomic case with protective rubber holster Specifications Technical Specification: Accuracy is ±(percentage of reading + number of digit) at (23±5) °C, <75% RH. DC Voltage Range Accuracy Resolution 400mV ±(0.5%+4d) 0.1mV 4V 1mV 40V 10mV 400V 100mV 1000V ±(1.0%+4d) 1V Input impedance: 400 mV range: more than 40MO ; other range: 10MO Overload protection: 1000 V DC or 750V AC peak value AC Voltage (only 400mV range has manual range) Range Accuracy Resolution 400mV ±(1.5%+6d) 0.1mV 4V ±(0.8%+6d) 1mV 40V 10mV 400V 100mV 750V ±(1.0%+6d) 1V Input impedance: 400 mV range: more than 40 MO ; other range: 10 MO Frequency response: 750 v range: 40-100 Hz ; other range: 40-400 Hz Overload protection: 1000 V DC / 750 V AC peak value DCA Range Accuracy Resolution 400uA ±(1.0%+5d) 0.1uA 4000uA 1uA 40mA 10uA 400mA 100uA 4A 1mA 20A ±(2.0%+5d) 10mA Max. Measuring volt drop: 400mV under mA range, 200mV under A range. Max. input current: 20A (less than 10 sec) Overload protection: 0.5/250V fuse, 15A/250V fuse ACA Range Accuracy Resolution 400uA ±(1.5%+5d) 0.1uA 4000uA 1uA 40mA 10uA 400mA 100uA 4A 1mA 20A ±(2.0%+10d) 10mA Max. Measuring volt drop: 400mV under mA range, 200mV under A range. Max. input current: 20A (less than 10 sec) Overload protection: 0.5/250V fuse, 15A/250V fuse Frequency response: (40~100)Hz under 20A range, (40~400) Hz at other range. Resistance Range Accuracy Resolution 400O ±(0.8%+5d) 0.1O 4kO ±(0.8%+2d) 1O 40kO 10O 400kO 100O 4MO 1kO 40MO ±(1.2%+5d) 10kO Overload protection: 250V DC/AC Peak Value Open circuit voltage: 400 mV Capacitance Range Accuracy Resolution 4nF ±(0.5%+20d) 1pF 40nF ±(3.5%+8d) 10pF 400nF 100pF 4uF 1nF 40uF 10nF 200uF ±(5.0%+8d) 100nF Overload protection: 250V DC/AC Peak Value Frequency Range Accuracy Resolution 10Hz ±(0.5%+4d) 0.01Hz 100Hz 0.1Hz 1000Hz 0.1Hz 10kHz 1Hz 100kHz 10Hz 1MHz 100Hz 30MHz 1kHz INPUT SENSOR: 0.7V Overload protection: 250V DC/AC Peak Value Diode and Continuity Test Range Description Test Condition Diode Display read approx.forward voltage of diode Forward DC Current approx 0.5mA Reversed voltage approx. 1.5V Buzzer Buzzer sounds if resistance between terminals V/ O and COM is less than (50± 10) O Open circuit voltage:0.5V Overload Protection: 250 V DC/AC peak value Warning: Do not input Voltage at the range for safety hFE Range Description Test Condition NPN or PNP 0 ~ 1000 Basic Current is Approx. 15 µA. Vce is approx. 4.5V Temperature Range Description Test Condition -40 - 1000 °C < 400 °C ± (0.8% + 4) =400 °C ± (1.5% + 15) 1 °C Thermocouple: K Type Warning: Do not input any voltage at this range Display: 3 3/4 digit Large LCD with a max readings of 3999 Measuring method: Dual-slope integrating A/D Converter System Sampling Rate: approx. 3 Times / Second Range Selection Method: Automatic and Manual Polarity: Automatic Negative Polarity Indication Over range indication: "OL" display Operating Temperature: 0 ~ 40°C; Operating Humidity: <80% RH Storage Temperature: -10 ~ 50°C; Storage Humidity: <80% RH Low battery indicator Power: 2 x 1.5V AAA batteries (included) Dimensions: 185(L) x 93(W) x 35(H) mm Weight: approx. 290g (including battery) Set Includes 1 x Auto/Manual Range Digital Multimeter 1 x pair of Test Leads 1 x K-Type Thermocouple Wire 2 x 1.5V AAA batteries (included) 1 x Non-slip Rubber Protection Cover 1 x English Instruction Manual Standard Factory Package Shipping : DELIVERY We ship worldwide to any destination whether you are from North America, South America, Asia, Australia / Oceania, Europe, Africa or the Middle East, we make sure that your order leaves our facility in a timely manner. All items are checked before dispatch and are carefully hand-packed by our in-house team. Shipping cost is specified above the listing. We will send the item(s) within 1 business day by Registered Airmail (with insurance) after cleared payment has been received. You will be notified when the item has been shipped. Please check your mailbox frequently. ** For United States, Canada, United Kingdom, Australia, New Zealand and Major Asian Countries, normal postage time is approximately 9 - 18 business days. ** For Western Europe and the rest of the world, normal postage time is approximately10 - 18 business days except for Italy. There are cases that due to customs problem postage time to Italy might have longer time. We charge the same shipping cost to customers worldwide (same shipping cost to United States, Europe and Australia) including insurance. DISCOUNT We do COMBINED SHIPMENT on any multiple purchases. We are pleased to grant a 10% discount on the shipping cost of purchases more than one (1) item. Please feel free to contact us for discounted shipping costs when you buy multiple items from us. We are also happy to offer personalized discounts for larger orders. RETURN & REPLACEMENT If the product malfunctioned under proper usage per instructions manual within the warranty period, please contact us to obtain shipping instructions and send it back at your shipping costs. A 7-days evaluation and investigation takes placed after receiving the returned item. A brand new replacement unit will be sent to you at our shipping costs if it meets our warranty requirements. CUSTOM, DUTIES, TAXES When orders shipped internationally reached the destination country, they may be subject to customs clearance procedures which can cause delays beyond original delivery estimates. Once a shipment reaches the destination country, the packages may be subject to customs fees and import duties & tax of the country to which you have your order shipped. These charges are always the recipient's responsibility. We have no control over these charges and cannot predict what they may be. Customs policies vary widely from country to country; you may contact your local customs office for further information. Payment : Payments are accepted through Paypal only. It's a quick, safe and free way to pay for your online purchases. Payments are instant, so we can prepare your order for shipping as soon as you have paid. Payment is expected within 7 days from end of auction. We will do a positive feedback once we have received your payment. Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge inkfrog terapeak

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	VC97
Measuring method	Dual-slope integrating A/D Converter System
MPN	VC97
Range Selection Method	Automatic and Manual
Type	Professional Auto-range Digital Multimeter
Dimension	185(L) x 93(W) x 35(H) mm
Display	3 3/4 digit Large LCD with a max readings of 3999
Weight	approx. 290g (including battery)
