Wavetek Acterna Mts-5100 5073 Wdm Optical Spectrum Network Analyzer Mts 5100

US $2,495.00

Toledo, Ohio, United States
Jun 9th

Open on mobile:
QR code

Content on this page requires a newer version of Adobe Flash Player. The Following Items Are Included: Wavetek MTS-5100 Media Test Set w/ Options (BC# 20756) COL: High Definition VGA Color Display: Active Matrix FD: Floppy Disk Drive HD: Hard Disk Drive Wavetek 5073 WDM Optical Spectrum & Network Analyzer Module (BC# 17612) SM FC-FC Fiber Cable MM FC-FC Fiber Cable (4) Fiber Wipes AC Adapter/Charger Power Cord RS232 PC Interface Cable User Manual On CD-ROM Carrying Case (G) BE SURE TO CHECK OUR EBAY STORE FOR OTHER ITEMS! This Item Has A Current Calibration! Wavetek MTS-5100 Media Test Set w/ Wavetek 5073 WDM Optical Spectrum & Network Analyzer Module Installed Options: - COL: High Definition VGA Color Display: Active Matrix - FD: Floppy Disk Drive - HD: Hard Disk Drive The 5073 WDM module tests all the parameters necessary for maintenance of the DWDM network, including channel wavelength, frequency, channel spacing, power and optical signal to noise ratio (OSNR) Includes Carrying Case & Accessories As Listed Above! Working Condition: Excellent Condition: Refurbished Calibrated: Yes Warranty: 90 Day Exchange Warranty Wavetek MTS 5100 Media Test Set New and enhanced network services require increased bandwidth, leading the communications industry to expand its test requirements. Advanced test and measurement needs call for advanced equipment, allowing craftsmen to perform multiple functions with a single test instrument. MTS 5100 is at the forefront of new OTDR technology. FEATURES Two bays available in the unit to house two optical test modules Quad wavelength singlemode and multimode OTDR for installations Link loss, fiber loss, event loss, return loss, ORL, end-to-end loss, and optical budget tests Short distance performance for building, riser, patch panel tests Long distance performance for amplified systems in supertrunking, SONET/SDH, and submarine cables OTDR and insertion loss test functions for fiber plant acceptance 1625nm module for testing fibers with live traffic VFL option for fault-finding in the OTDR deadzone Small and compact at less than 3.5kg (7.8lbs) Water and dust resistant with all input/output connectors protected from the elements Extended operating life of up to 16 hours Intelligent battery management with charge indicator, rapid two hour charging, and optional 12VDC adapter Fast processing for immediate results and on-site analysis for cable restoration Universal optical connectors increase flexibility Fast real-time sweep (0.5s) for mechanical splicing and bare fiber testing Super-fast data processor reaches maximum dynamic range in less than one minute Up to 32000 data points for maximum resolution at 16cm sampling Down to 1m event deadzone and up to 35dB dynamic range with DR OTDR module High dynamic range (40dB) OTDR module for long haul testing Full Bellcore GR196 data compliance Automatic detection of splices or fiber bends down to 0.01dB Macro function for dual wavelength testing in one step Universal Test Set The Universal Test Set concept outlines the requirements and objectives for multifunction, compact test gear. Documented by Bellcore, the concept can be found in GR-2876-CORE Generic Requirements for Universal Test Sets from December 1995. Today, telecommunications, cable television, and data communications users appreciate the advantages of more portable test gear with expanded capabilities and a common user interface. MTS 5100 Media Test Set With the MTS 5100, Wavetek is one of the first companies to develop and market a modular OTDR that embodies the Universal Test Set concept. Based upon the latest RISC microprocessor interfacing with modular architecture, the MTS provides excellent performance and enhanced field modularity. MTS provides a comprehensive set of optical test functions for incoming test, fiber plant construction, splicing, cable acceptance, and cable restoration. MTS tests short or long haul fiber networks in singlemode or multimode applications. Two optical module bays allow the user to configure and upgrade the tester in the field, while the familiar user interface and integrated help functions simplify testing. Multiple Test Functions In A Single Unit The MTS is designed to integrate several field test functions in a single unit. Two slots are provided for optical modules, and the user can mix and match the test configuration according to the testing needs at hand. Typical MTS configurations include a four window 850nm to 1550nm dual port multimode and singlemode OTDR, or a dual wavelength OTDR with a complete set of insertion loss tests with integrated light source and power meter. Complete User Flexibility With over nine available OTDR modules, the user is equipped to cost-effectively test short and long spans of fiber at all operating wavelengths with maximum precision. The 1625nm OTDR module is ideal for systems applications where fiber is tested outside wavelengths used for traffic. To ease fiber tracing in multifiber cables, the visible light source option illuminates and identifies the fiber connected to the source. An additional module allows users to combine a light source, power meter, and optical talk set providing all necessary functions for effective insertion loss testing. Upgradable Investment The MTS modular concept reduces the number of different testers required for the job and eases instrument stock monitoring. Whether you need test equipment today for short or long haul cables, point-to-point or complex branching systems, or multimode or singlemode networks, MTS provides both an immediate solution and an upgrade path for future transport technologies. Optimized for Field Use Optical test equipment needs to couple high performance with maximum portability to be productive in the field. MTS has a small footprint to ease testing in areas with limited access such as crowded wiring closets or underground enclosures. A hardened outer case with protective bumpers ensures that the unit survives even the harshest conditions. Efficient Testing of High Count Cables MTS provides extremely rapid sweep times, straightforward and vivid presentation of the fiber trace and results, and fast storage possibilities with SRAM or other internal memory devices. These features are particularly useful for fiber plant commissioning where the requirement for two-way measurements at both wavelengths demands high productivity. Extended Battery Life Improves Productivity Testing high fiber count cables requires a unit that can operate for extended periods on battery. With a maximum operating time of 16 hours, MTS is at the top of its class in this category. Its internal battery compartment accommodates up to two removable, rechargeable Nickel Metal Hydride cells. Simple User Interface Reduces Training Requirements MTS has a familiar, intuitive user interface, requiring little to no training for experienced OTDR users, and shortening the learning curve for novices. Simple direct access keys make primary test functions available to the user at the push of a button for maximum productivity, while results are logically organized on the large color display for easy interpretation. High Performance for the Novice and the Expert For the novice, simply pressing the START button immediately auto configures the measurement parameters for optimal test performance. For more experienced users, advanced trace analysis functions are also accessible. After acquiring traces, a variety of standard data communications interfaces support download for analysis or direct printing, making the MTS a complete workstation. Maximum Speed and Precision MTS provides the user with an unprecedented level of speed, processing power, resolution, and range. Its extremely short deadzones can be used for pinpointing faults close to cable junctions or splice points. Impressive dynamic range means that even the longest fibers can be characterized with confidence. Flexible Data Storage and Retrieval Results can be imported and exported in Bellcore format and other standard industry formats, allowing easy integration into existing databases. Data can be stored in the standard internal memory (up to 200 traces), or on internal floppy or hard disk. Optional 1GB hard disk drive capacity is useful for commissioning and acceptance tests on high fiber count cables, while an auto-incrementing file utility simplifies storage and retrieval. Passive color, 7.8 inches LCD 640 x 480 Active TFT color, 8.4 inches LCD 640 x 480 Languages English, French, German, Spanish, Portuguese, Italian, Chinese, Taiwanese, Russian, Korean, Japanese, Turkish Weight 3.5 kg (7.7 lb) including 1 module and 1 battery Size 300 x 235 x 90 mm 11.8 x 9.25 x 3.5 in Input/Output RS-232-C, Centronics interface, external keyboard (optional), Ethernet interface (optional) Power supply AC or internal removable NiMH batteries Operation time up to 16 hours with 2 batteries (Bellcore GR-196) Internal charger Charging time < 3 hours per battery DC input 11 to 14 V AC adapter MTS-5100 Input 100-250 V, 50-60 Hz, 1.6 A, Output 12 V DC / 4.2 A Results display dBm, dBr, nW, A¬W, mW Temperature range Operating AC Power (no options) 20 °C to 50 °C (4 °F to +122 °F) Operating with all options 0 °C to 40 °C (+32 °F to +104 °F) Storage 20 °C to 60 °C (4 °F to +140 °F) Humidity 95% without condensing EMI/ESD CE compliant Wavetek 5073 WDM Module for C+L Band Features: Maintenance of C+L band (1525-1610nm) Up to 256 channels High wavelength accuracy No moving parts Enables OTDR and WDM testing in a single unit Up to 16 hours of operation Comprehensive user interface with one button testing Automatic channel detection and measurement The 5073 WDM plug-in module for the MTS 5100e/5200e family is a cost-effective solution for DWDM network maintenance in the C+L band (1525-1610nm). Comprehensive DWDM test The 5073 WDM module tests all the parameters necessary for maintenance of the DWDM network, including channel wavelength, frequency, channel spacing, power and optical signal to noise ratio (OSNR). Fast Acquisition and Analysis of DWDM Data « One button testing » means that 5073 WDM module performs all data acquisition and analysis with a single key-stroke. Parameters are presented over the full spectrum in wavelength and tabular formats, with a handy zoom function for more detailed analysis. Efficient Testing of High Fiber Counts To speed multiple fiber testing, 5073 WDM module features a macro function which can be user-programmed for automatic, successive measurement and analysis of large quantities of fibers. All the test modules in the MTS 5100e/5200e range allow « multi-tasking » for continued data acquisition while test parameters are set-up or results are printed. Advanced Modularity for the Field The MTS 5100e and 5200e are the ideal platforms for outside plant applications. Equipped with the 5073 WDM module, the MTSe is the perfect tool to maintain DWDM networks. Optimized for field use (lightweight with 3.5 kg, up to 16 hours of operation and with no moving parts), it provides all test parameters to analyze the quality of a DWDM network of up to 10 Ghz channel spacing. The WDM module is a new member of the family of MTSe modules, which include the essential tools for installation and maintenance of fiber optic links : OTDR, loss test set, Visual Fault Locator, talk set. Switching between functions takes only seconds, enabling the user to concentrate on measurement or results, rather than on instrument configuration. The MTSe platform is the only unit able to measure fiber optic parameters and WDM parameters within seconds, without the need to swap modules. Ready for Comprehensive Measurements and Statistical Analysis Configurable user interface The intuitive interface of the 5073 WDM module is highly user-configurable. Measurement units (nm or THz), SNR measurement set-up (left, right, left and right or custom) and grid (ITU or manual) are user-specified, and channels can be sorted by number, wavelength, power level or OSNR. Comprehensive measurements In addition to the main DWDM parameters which are measured automatically at the touch of a button, the 5073 WDM module can be used to compare total or partial optical power, level, wavelength, gain tilt and gain slope between two points. An innovative overlay function makes it easy to compare stored waveforms. Statistical Analysis The 5073 WDM module can be used for statistical analysis of the results of longterm monitoring. User-defined limits identify potential problems, for effective preventative maintenance of the network. File Management The 5073 WDM module has a comprehensive file management system, which allows successive files to be named and stored automatically, semi-automatically or manually. Automatic Maintenance Testing During maintenance operation of a DWDM network, it is essential to have accurate knowledge of the optical spectrum, primarily the individual channel power and wavelengths, at critical points along the optical link : end terminals, optical amplifiers, add/drop nodes, cross connects and any other locations. Measuring the performance enables the operator to identify degradation or failure. Complete Channel Analysis The MTSe automatically provides all the necessary parameters to maintain a DWDM network. By pressing a single key, the MTSe performs an acquisition followed immediately by an analysis of the existing channels. This enables the user to rapidly detect if a channel is lower in power or missing, or if the entire network has been degraded. Measurement parameters are presented over the full spectrum in a waveform, as well as in a tabular display. For easy analysis, a simple 'click' on the table brings the relevant waveform center screen, with a zoom function available for more detailed analysis. The MTSe automatically provides the following measurements for each channel: Number Wavelength Spacing Power level SNR Ratio between channel power level and composite power level Composite power is also displayed, and slope gain and tilt gain are provided to indicate the quality of the amplified system. Specifications Wavelength parameters Range 1525 to 1610 nm Display resolution 1:00 PM Accuracy +/- 10 pm Minimum channel spacing 0.08 nm (10 Ghz) Power level parameters Display range -90 to +30 dBm (+20 dBm Composite power, +10 dBm channel power) Display resolution 0.01 dB Accuracy +/-0.5 dB (-30 dBm, 1550 nm) Linearity (typical) +/- 0.1 dB (-40 to +10 dBm) Optical Rejection Ratio 40/34 (0.8 / 0.4 nm) Polarization dependance +/-0.2 dB Optical return loss >35 dB Sweep time 1.5 s (real time) Please check our Huge Inventory with savings of up to 80% off of retail on Cat5/5e/6 LAN Cable Certifiers and Fiber Optic OTDR's, Fusion Splicers, CATV Meters, Fiber Optic Kits, Sources, Meters, Tools, Network Analyzers and much more. Here is a Link to our Ebay Test Equipment Store. All of our Test Equipment is backed with a Full Warranty and unbeatable customer support & service. Please don't hesitate to contact us for a Quote on Something you don't see in our inventory, sometimes we have items that may have not been listed or processed yet. Test Equipment Store Offers a wide range of Refurbished Telecom/ Datacom Tools and Test Measurement Equipment. Which includes Fiber Optic Test and Splicing tools, Fusion Splicers, OTDRs, Copper and Fiber Cable Certifiers, CATV Test Equipment, Cable and Antenna Analyzers, Network Analyzers and much more! We carry a large inventory of quality refurbished and used test equipment from all the major manufacturers. If you are looking for multiple quantities or if we don't have a listing for a particular item that you are looking for. Please contact us as it may be fresh inventory waiting to be listed or we'll be glad to find it for you at the best price possible and put up an eBay listing for you! Contact: Test Equipment Store eBay Sales Phone: 1-419-517-6681 Toll Free : 1-800-548-2381 We Ship World Wide! We will attempt to ship your item(s) within 24 hours after payment has been received. To get a real-time shipping quote to your destination, enter your country and zip / postal code information into the shipping calculator and click "Get Rate". Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do not cover those cost's and we recommend that you contact your countries customs agency for that information. We Offer Multiple Quantity Price & Shipping Discounts, Email Us If You Are Interested In Larger Quantities. UPS Ground United States USD 0.00 USPS Express Mail International (EMS) Worldwide USD 0.00 We accept credit card payment transactions via the online checkout system! The checkout process is designed so that it communicates with the merchant to confirm that payment has been made and cleared. Other methods of payment are outlined through the online checkout process. Winning bidders must contact us within 3 days after auction close if special payment arrangements are needed. Your payment is expected within 5 days after the auction close. Unpaid auctions will be forfeited after 5 days of the auction close and the Item(s) will be relisted for sale. Items will be shipped within 24 hours (1 Business Day) upon receipt of payment from the winning bidder. (Certain orders may take longer for processing due to comprehensive final service inspections) A Shipment Tracking number(s) will be provided to inform Buyers of their expected ETA (Estimated Time of Arrival). Tracking number(s) will be provided the same day as order shipment. Thank you ALL MAJOR CREDIT CARDS & PayPal ACCEPTED Put your listings on autopilot with Kyozou eBay Listing Management Software

Condition:	Seller refurbished: An item that has been restored to working order by the eBay seller or a third party not approved by the manufacturer. This means the item has been inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See the seller’s listing for full details. ...	Brand	Wavetek
Model	MTS-5100
