Whirli-gig Sine Plate

US $1300

  • Cranesville, Pennsylvania, United States
  • Jun 12th
Open on mobile:
QR code
This USA custom made Whirli-Gig sine plate allows you to use your Whirli-Gig to grind angles on your work pieces without the need to use a magnetic sine plate underneath it which increases the weight on your grinder and reduces the working height under the wheel as the stack up of tooling consumes the space. The sine plate is made using hardened A2 tool steel for the top and bottom plates and the rolls are hardened O1 tool steel. The top plate is reversible on the base rolls to allow the angle to be set to a positive or negative incline depending upon the work requirements. The stationary roll has .2000" step on each end for setting minor angles and the sine plate locks on both sides allow accurate angle setting without twisting the top plate. These are custom made to fit the bolt pattern of your Whirli-Gig and the rails are designed to locate the Whirli-Gig on the center of the top plate. Please allow 5 weeks for manufacture and shipment from order, and upon supplying the bolting requirements and base width for your Whirli-Gig. The base plate is 6" x 6", the top plate is 6" x 12" and the rolls are at 5" centers for sine setting with gage blocks. Whirli-Gig pictured for demonstration purposes only and is not included with the sine plate. You get the complete sine plate, two rails, and two locks. Returns are subject to a 25% restocking fee plus shipping since they are custom made to suit your equipment.
