X-nucleo-idb04a1 Bluetooth Low Energy Arduino Expansion Kit Bluenrg Stm32 Nucleo

US $22.99

shenzhen, guangdong, China
Jun 9th

Open on mobile:
QR code

This auction is for X-NUCLEO-IDB04A1 X-NUCLEO-IDB04A1, Bluetooth low energy expansion board based on BlueNRG for STM32 Nucleo Description The X-NUCLEO-IDB04A1 is a Bluetooth low energy evaluation board to allow expansion of the STM32 Nucleo boards. It is compatible with the Arduino UNO R3 connector layout, and is designed around BlueNRG, a Bluetooth low energy, low power network coprocessor compliant with BTLE 4.0 and the BALF-NRG-01D3, an ultra miniature balun optimized for ST BlueNRG RF IC, which integrates matching network and harmonics filter. The X-NUCLEO-IDB04A1 interfaces with the STM32 MCU via SPI pin, and the user can change the default SPI clock, the SPI chip select and SPI IRQ by changing one resistor on the evaluation board. The excellent performance of BlueNRG and the best matching between BlueNRG and BALF-NRG-01D3, X-NUCLEO-IDB04A1 passed the RF TEST for Japan Radio Law certification with higher margin above the specification values as well as it is FCC certified (FCC ID: S9NIDB04A1). Key Features BlueNRG low power, low energy Bluetooth network coprocessor BALF-NRG-01D3 balun & harmonic filter Free comprehensive development firmware library and example for BlueNRG, compatible with STM32Cube firmware Bluetooth low energy 4.0 master and slave compliant Compatible with STM32 Nucleo boards Equipped with Arduino UNO R3 connector Very low power consumption: 7.3 mA RX and 8.2 mA TX at +0 dBm Maximum transmission power: +8 dBm Excellent receiver sensitivity (-88 dBm) X-NUCLEO-IDB04A1 is FCC certified (FCC ID: S9NIDB04A1) X-NUCLEO-IDB04A1 is officially certificated as a BTLE 5mW module for Japan Radio Law “TYPE” Certification by Japan government RoHS compliant Photos X-NUCLEO-IDB04A1 Packaging X-NUCLEO-IDB04A1 Packaging Back View X-NUCLEO-IDB04A1 X-NUCLEO-IDB04A1 Back View X-NUCLEO-IDB04A1 X-NUCLEO-IDB04A1 Back View What's Onboard Application Diagram Working with an STM32L MCU : Development Resources User manual Schematic Demo code Development software Wiki : www.waveshare.com/wiki/X-NUCLEO-IDB04A1 Package Contains X-NUCLEO-IDB04A1 x 1 Terms & Conditions Payment: · PayPal is the only method of payment that we accept. Shipping: · We ship items to Worldwide! · Please confirm your address in paypal, phone number is also very important. · All items will be shipped within 48 working hours on receipt of cleared payment. · We'll add a tracking number after sending the item so that you can track your parcel. Returns Policy: · We are happy to return any unused item in its original packaging within 14 days of delivery. · Buyers are responsible for the round(two-way) shipping cost. Feedback: · We'll leave POSITIVE FEEDBACK on receipt of cleared payment. · If you're satisfied with the item and our service, please leave POSITIVE FEEDBACK, it's important to us. · Once any problems occured, please contact us first. We'll try our best to work things out. FAQ: · More details(Click) If you have any question, please feel free to contact us. It's our pleasure to serve you! We appreciate your business!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	STMicroelectronics
MPN	X-NUCLEO-IDB04A1
Model	X-NUCLEO-IDB04A1
Country/Region of Manufacture	China
UPC	712321341402
