X-nucleo-ihm01a1 L6474 Stepper Motor Driver Arduino Expansion Board Stm32 Nucleo

US $17.99

shenzhen, guangdong, China
Jun 9th

Open on mobile:
QR code

This auction is for X-NUCLEO-IHM01A1 X-NUCLEO-IHM01A1, Stepper motor driver expansion board based on L6474 for STM32 Nucleo Description The X-NUCLEO-IHM01A1 is a stepper motor driver expansion board based on the L6474. It provides an affordable and easy-to-use solution for driving a stepper motor in your STM32 Nucleo project. The advanced current control of the L6474 and a complete set of protection features offer high levels of both performance and robustness. The X-NUCLEO-IHM01A1 is compatible with the Arduino UNO R3 connector, and supports the addition of other boards which can be stacked to drive up to three stepper motors with a single STM32 Nucleo board. Key Features Voltage range from 8 V to 45 V Phase current up to 3 Ar.m.s. Power OK and fault LEDs Advanced current control Fully protected power stage Up to 1/16 microstepping resolution Compatible with Arduino UNO R3 connector Compatible with STM32 Nucleo boards Suitable for multi-motor solutions RoHS compliant Photos X-NUCLEO-IHM01A1 Packaging X-NUCLEO-IHM01A1 Packaging Back View X-NUCLEO-IHM01A1 X-NUCLEO-IHM01A1 Back View X-NUCLEO-IHM01A1 X-NUCLEO-IHM01A1 Top View What's Onboard Application Diagram Drive three stepper motors with a single STM32 Nucleo board : Development Resources User manual Schematic Demo code Development software Wiki : www.waveshare.com/wiki/X-NUCLEO-IHM01A1 Package Contains X-NUCLEO-IHM01A1 x 1 Terms & Conditions Payment: · PayPal is the only method of payment that we accept. Shipping: · We ship items to Worldwide! · Please confirm your address in paypal, phone number is also very important. · All items will be shipped within 48 working hours on receipt of cleared payment. · We'll add a tracking number after sending the item so that you can track your parcel. Returns Policy: · We are happy to return any unused item in its original packaging within 14 days of delivery. · Buyers are responsible for the round(two-way) shipping cost. Feedback: · We'll leave POSITIVE FEEDBACK on receipt of cleared payment. · If you're satisfied with the item and our service, please leave POSITIVE FEEDBACK, it's important to us. · Once any problems occured, please contact us first. We'll try our best to work things out. FAQ: · More details(Click) If you have any question, please feel free to contact us. It's our pleasure to serve you! We appreciate your business!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	STMicroelectronics
Country/Region of Manufacture	China
Model	X-NUCLEO-IHM01A1
On board chip	L6474
MPN	X-NUCLEO-IHM01A1
UPC	712321341396
