Yarn Meter Tachometer, Non-contact 1.00 - 99,999 Rpm Contact 1.00 - 19,999 Rpm

US $643.00

Forest Hills, New York, United States
Jan 30th

Open on mobile:
QR code

Product DescriptionThe Checkline YSL-2000HD Yarn Meter Tachometer, Range: Non-Contact 1.00 - 99,999 rpm Contact 1.00 - 19,999 rpm is a precision instrument that combines the functions of three separate instruments in one, easy-to-use device. It accurately measures the speed and length of yarns, wires and other filaments using a unique "wrapper" roller. This precision roller directs the filament onto the low-inertia, U-grooved measuring wheel to maximize contact and eliminate filament slip and breakage. The YSL-2000HD Yarn Meter can also be used as either a contact or non-contact tachometer to measure rotational speeds of shafts, motors, pulleys, etc. or linear speeds of moving surfaces such as conveyor belts, webs of paper or fabric, etc. Product Features Combination Contact & Non-Contact Tachometer Slide-on measuring heads make it simple to rapidly convert from one function to another Accuracy of 0.02% Built-in memory for last, maximum, minimum values 5 Year Warranty NIST Certification Included Product Specifications RPM Non-Contact; 1.00 - 99,999 rpm Contact; 1.00 - 19,999 rpm Surface Speed 0.30 - 6,500 feet/min 0.10 - 1,999 meters/min 4.0 - 78,000 inches/min Length 0.01 - 99,999 feet 0.02 - 99,999 meters 1.0 - 99,999 inches Resolution .01 from 0 - 100 .1 from 100 - 1,000 1 from 1000 - 99,999 Yarn/Wire Diameter (max.) Yarn; 1mm Wire; 0.3mm Accuracy ± 0.02% of reading or 1 digit Display 5 - Digit LCD, 10mm high Decimal Point Automatic Memory System Maximum, minimum, and last reading (retained in memory for the life of the batteries) Measurement System Non-Contact; Visible LED light beam Contact; Contact adapter Sensing Distance Up to 14 inches (350mm) Display Update Time 0.5 seconds or one measuring Auto Power Off After 30 seconds of non-use (minimum, maximum and last reading retained in memory) Battery Life 20 hours continuous use Weight 6 ounces (170 grams) Housing Material ABS Plastic Operating Temp 32 to 122° F (0 to 50° C) Storage Temp -4 to 150° F (-20 to 70° C) Accessories Shaft extension, 3.15 inches (80 mm) Warranty 5 years Kit Contents The YSL unit, two slide-on measuring heads (tachometer and yarn speed), cone tip, universal surface speed wheel with integrated funnel tip adapter, reflective tape, two AA batteries and operating instructions, all supplied in a foam-fitted, hard-plastic carrying case.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Manufacturer	Checkline
MPN	YSL-2000HD
Country of Manufacture	United States
