Zaber Technology Motorized Linear Slide, 450 Mm Travel, T-lsr450b, S/n 16829

US $2,800.00

  • Saint Paul, Minnesota, United States
  • Jan 29th
Open on mobile:
QR code
 Zaber Technologies Motorized Linear Slide 450 mm travel Specification (click for definition) Value Alternate Unit Microstep Size (Default Resolution) 0.49609375 µm Integrated Controller Yes Travel Range 450 mm 17.717 " Accuracy (unidirectional) 45 µm 0.001772 " Repeatability < 2.5 µm < 0.000098 " Backlash < 7 µm < 0.000276 " Maximum Speed 20 mm/s 0.787 "/s Minimum Speed 0.00465 mm/s 0.00018 "/s Speed Resolution 0.00465 mm/s 0.00018 "/s Encoder Type None Peak Thrust 200 N 44.9 lb Maximum Continuous Thrust 100 N 22.4 lb Communication Interface RS-232 Communication Protocol Zaber Binary Maximum Centered Load 200 N 44.9 lb Maximum Cantilever Load 800 N-cm 1,132.9 oz-in Guide Type Roller bearing Vertical Runout < 13 µm < 0.000512 " Horizontal Runout < 13 µm < 0.000512 " Pitch 0.05 degrees 0.873 mrad Roll 0.01 degrees 0.175 mrad Yaw 0.02 degrees 0.349 mrad Maximum Current Draw 550 mA Power Supply 12-16 VDC Power Plug 2.1 mm center positive Linear Motion Per Motor Rev 6.35 mm 0.250 " Motor Steps Per Rev 200 Motor Type Stepper (2 phase) Inductance 28 mH Default Resolution 1/64 of a step Data Cable Connection Minidin 6 M/F Mechanical Drive System Precision lead screw Limit or Home Sensing Magnetic home sensor Manual Control Knob with center detent Axes of Motion 1 LED Indicators Yes Mounting Interface M6 threaded holes and 8-32 threaded holes Vacuum Compatible No Compatible Products T-LS Motorized Stages, TSB Manual Translation Stages Operating Temperature Range 0 to 50 degrees C Stage Parallelism < 100 µm < 0.003937 " RoHS Compliant Yes CE Compliant Yes Weight 2.30 kg TERMS OF SALE $40 shipping to the Continental US $80 shipping cost to HI, PR, AK, and Canada  PayPal usually ships within 24 hours Thank you for your interest Please email me with any questions, comments, or concerns
Condition Used :
An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes “Minimal marks or scratches. Nothing performance-altering.”
