2pc Beckhoff Kl3012

US $310

Rechitsa, Gomelskiu, Belarus
Jan 29th

Open on mobile:
QR code

KL3011, KL3012 | 1-, 2-channel analog input terminals 0…20 mA The KL3011 and KL3012 analog input terminals handle signals in the range from 0 to 20 mA. The current is digitised to a resolution of 12 bits and is transmitted, in an electrically isolated form, to the higher-level automation device. The input channels of the Bus Terminals have differential inputs and possess a common, internal ground potential. The KL3011 is the single-channel variant and is characterised by its fine granularity and electrical isolation. The KL3012 combines two channels in one housing. An open lead or overload condition are detected, and the terminal status is relayed to the controller via the K-bus. The run LEDs give an indication of the data exchange with the Bus Coupler. The error LEDs indicate an overload condition and a broken wire. Technical data KL3011 | KS3011 KL3012 | KS3012 Number of inputs 1 2 Power supply via the K-bus Signal current 0…20 mA Technology differential input Internal resistance 80 ? + 0.7 V Common-mode voltage UCM 35 V max. Resolution 12 bit Conversion time ~ 1 ms ~ 2 ms Measuring error < ±0.3 % (relative to full scale value) Surge voltage resistance 35 V DC Electrical isolation 500 V (K-bus/signal voltage) Current consumption power contacts – (no power contacts) Current consumpt. K-bus typ. 60 mA Bit width in the process image input: 1 x 16 bit data (1 x 8 bit control/status optional) input: 2 x 16 bit data (2 x 8 bit control/status optional) Weight approx. 70 g Operating/storage temperature 0…+55 °C/-25…+85 °C -25…+60 °C/-40…+85 °C Relative humidity 95 %, no condensation Vibration/shock resistance conforms to EN 60068-2-6/EN 60068-2-27 EMC immunity/emission conforms to EN 61000-6-2/EN 61000-6-4 Protect. class/installation pos. IP 20/variable Pluggable wiring for all KSxxxx Bus Terminals Approvals CE, UL, Ex, GL

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	BECKHOFF
Country/Region of Manufacture	Germany
Model	KL3012
