2PC BECKHOFF KL3202, US $860 – Picture 0

2PC BECKHOFF KL3202, US $860 – Picture 1

2pc Beckhoff Kl3202

US $860

Rechitsa, Gomelskiu, Belarus
Jan 29th

Open on mobile:
QR code

KL3201, KL3202 | 1-, 2-channel input terminals PT100 (RTD) The KL3201 and KL3202 analog input terminals allow resistance sensors to be connected directly. The Bus Terminal’s circuitry can operate the sensors using 2-wire or 3-wire connection techniques. Linearisation over the full temperature range is realised with the aid of a microprocessor. The temperature range can be selected freely. The Bus Terminals standard settings are: resolution 0.1 °C in the temperature range of PT100 sensors in 3-wire connection. The run LEDs give an indication of the data exchange with the Bus Coupler. The error LEDs indicate sensor faults (e.g. a broken wire). Technical data KL3201 | KS3201 KL3202 | KS3202 Number of inputs 1 2 Power supply via the K-bus Technology 2-/3-wire Sensor types PT100, PT200, PT500, PT1000, Ni100, Ni120, Ni1000 resistance measurement (e.g. potentiometer, 10 ?…1.2/5 k?) Connection method 2- or 3-wire (default: 3-wire) Measuring range -200…+850 °C (PT sensors); -60…+250 °C (Ni sensors) Resolution 0.1 °C per digit Conversion time ~ 200 ms ~ 250 ms Measuring current typ. 0.5 mA Measuring error < ±1 °C Electrical isolation 500 V (K-bus/signal voltage) Current consumption power contacts – (no power contacts) Current consumpt. K-bus typ. 60 mA Bit width in the process image input: 1 x 16 bit data (1 x 8 bit control/status optional) input: 2 x 16 bit data (2 x 8 bit control/status optional) Configuration no address setting, configuration via Bus Coupler or controller Special features open-circuit recognition Weight approx. 70 g Operating/storage temperature 0…+55 °C/-25…+85 °C -25…+60 °C/-40…+85 °C Relative humidity 95 %, no condensation Vibration/shock resistance conforms to EN 60068-2-6/EN 60068-2-27 EMC immunity/emission conforms to EN 61000-6-2/EN 61000-6-4 Protect. class/installation pos. IP 20/variable Pluggable wiring for all KSxxxx Bus Terminals Approvals CE, UL, Ex

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	BECKHOFF
Country/Region of Manufacture	Germany
Model	KL3202
