Planetary Gearbox Reducer Nema23 Ratio 12:1 Stepper Servo Cnc Router Mill Plasma

US $8600

  • Torornto, ON, Canada
  • Jun 8th
PLANETARY GEARBOX RATIO 12:1 Nema23 Front & Back Frame size HIGH PRECISION GEARBOX SERVO, STEPPER & DC MOTORS MECHANICALLY REDUCE THE STEP IT WILL CREATE 10 TIMES HIGHER TORQUE AND PRECISION Specification on http://motiontek.ca/gear_reducer.html Drawings on http://www.motiontek.ca/pdf/GR-2310H.pdf CNC ROUTER, CNC PLASMA, CNC LASER, CNC LATHE & OTHER AUTOMATION MACHINE - Backlash < 10 arc-min - Gear Ratio 12:1 - Nominal Torque 35 NM - Front Frame Nema23 - Back Farme Nema23 - Maximum Input RPM 5000 - Rated Input RPM 3000 - Input clamping : Coupling - Output shaft diameter 12.7mm/0.5" - Output shaft length 32mm/1.26" - Input shaft diameter 6.35mm/1/4"  - Input shaft length 36mm/1.41" - Lifetime Lubrication
