100pcs Angle 2edgk-5.08-2p Pitch Screw Terminal Block Connector Pcb Mount

US $24.99

  • Shenzhen, China
  • Jan 29th
  100 Pcs Angle 5.08mm Pitch 2 way/pin Screw Terminal Block Connector 2EDGK-5.08-2P + Free shipping Model:#1279 Quantity: 100 Pcs Condition: Brand New Spec: Material - Housing:     PA66   UL94V-0 - Contact: Phosphor bronze,Ni plated - Solder pin: Brass,Tin plated - Screw:       M2 ,Steel,Zinc plated Electrical - Rated voltage:              300V - Rated current:              8A - Insulation resistance:   5000M?/1000V - Contact resistance:      20m? - Withstanding voltage:  2000V/1min - Wire range:              26~16AWG Mechanical & operating ambient - Torque:            0.2Nm - Strip length:        5~6mm - Temp.Range:     -40°C~+105°C - MAX soldering:  +250°C 5Sec Part. No.: DJ:2EDGK-5.08-2P  For PCB female PCB terminals fit for this item, please visit the following link : 1) 100pcs 2 Pin 2-way 5.08mm Pitch Screw Terminal Block Connector Panel Angle: http://www.ebay.com/itm/100pcs-2-Pin-2-way-5-08mm-Pitch-Screw-Terminal-Block-Connector-Panel-Angle-/190831003214?pt=LH_DefaultDomain_0&hash=item2c6e6a064e 2) 100pcs 2 Pin / way 5.08mm Pitch Screw Terminal Block Connector 2EDGV-2P-5.08: http://www.ebay.com/itm/100pcs-2-Pin-way-5-08mm-Pitch-Screw-Terminal-Block-Connector-2EDGV-2P-5-08-/190831003216?pt=LH_DefaultDomain_0&hash=item2c6e6a0650 3) 100pcs Angle 2 Pin 2-way 5.08mm Pitch Screw Terminal Block Connector Pluggable: http://www.ebay.com/itm/100pcs-Angle-2-Pin-2-way-5-08mm-Pitch-Screw-Terminal-Block-Connector-Pluggable-/190831003223?pt=LH_DefaultDomain_0&hash=item2c6e6a0657 If you do not find the model you need, please contact us freely.
