5mhz 1mhz 100khz Frequency Rubidium Standard Cchb-74 An-g Agilent Hp

US $4,980.00

Lviv, Europe, Ukraine
Jan 29th

Open on mobile:
QR code

Frequency Rubidium Standard CCHB-74 analog of Lutron, Advantest, Avtech, HP Agilent, NoiseCom, General Radio, Boonton, Anritsu, Fluke and general Electric, but has the same or better characteristics. This device can be used for wide measurement range. Condition: NEW (not used, an old stock). Tested and 100% workable. If necessary, we can provide calibration certificate from Government standardization institute (+145-265usd). Also we can provide other resistance, capacitance and inductance standards, decade box and other etalons. Also we can provide other resistance, capacitance and inductance standards, decade box and other etalons. Please take a look on my other items! If you haven’t found the needed item in my listing, please contact me. I’ll try to help you. Technical characteristics of devices Frequency standard CCHB-74 : Output signals nominal frequency value - 5MHz, 1MHz, 100kHz; Frequency at release relative error - is not more than ± 2 • 10-11; Limb measurements - area C from 45 to 145; CCHB-74 rms frequency deviation: - For 1s - is not more than 2 • 10-11; - For 10s - is not more than 1.4 • 10-11; Average relative frequency measurement per day - ia not more than ± 3 • 10-12 (± 1 10-12); Rms frequency variation per day - is not more than 6 • 10-12 (3 • 10-12); Output voltage signals at load 50 Ohm: - 5 MHz - 1 V ± 0.2 V; - 1 MHz - 1 V ± 0.2 V; - 100 kHz - 1 V ± 0.2 V; CCHB-74 relative frequency tuning range - 19 • 10-10 ± 5 • 10-11; Time signals parameters: - amplitude pulse at load 50 Ohm - is not less than 2.5; - delay pulses range 0.1 mks – 0 mks - 999999.9 mks; - time scale synchronize with external pulse keeper with error - is not more than ± 0.1 mks; - Error in measuring pulses time shift of external time scale - is not more than ± 0.05 mks. Power supply of frequency standard CCHB-74 - from a stationary or on-board power supply and DC power supply; Parameters of power supply networks are: - 220V ± 22V, frequency 50Hz ± 0,5 Hz - stationary power network; - 115 V ± 5,75 V, frequency 400 Hz ± 10 Hz - onboard power supply network; - 27V ± 3V - a constant current source; Dimensions of the device frequency standard CCHB-74 - 480X160X475mm; Weight - 23 kg; The device has a display of the current time in hours, minutes, seconds; Warranty 12mounth. Delivery term This device is available in stock right now. I can send it at one day after your payment. But due to the fact, that this device is of high precision, it should be calibrated before shipping. I calibrate and test all my devices. Calibration time may take from 1-14 days. (depends on device, usually it takes 3 days.). I can send it at one day after your payment but without any calibration. Please chose. I can supply you such device of fresh years of manufacture 2011-2012, but the price of such device will be approximately 20-40% higher or more. This device also can be named as: CCHB-74 , CCHB74, CCHB 74, ???74, ???-74, ??? 74. Photos If necessary we can take photos of a device from various angles. Technical Documentation In case you didn't find in technical specifications for the device all necessary information you are interested in, feel free to contact me. I will look through the technical documentation for the device and I will be happy to consult you. Also I may speak directly with the manufacturer and find out more specific information about this product. If some technical parameters for the device (error, accuracy, measuring range, operating voltage and frequency) do not meet your requirements, please, e-mail me and I will negotiate with the manufacturer whether it is possible to deliver you a device on the desired specifications without a cost increase and in the shortest time. On delivering the device, electric circuit diagrams and all technical documentation for operation, calibration and maintenance will be supplied. Also there will be documents that testify the accuracy and compliance with specifications. In addition, translation of technical documentation into the customer’s language may be discussed. Delivery set On delivering the device will be completely ready for use. There are all necessary cables, adapters, sensors and spare parts as envisaged in technical documentation. Hence, there is no point in purchasing any additional repair & measurement equipment. Warranty Warranty of this item - 12 month. Before sending a device, all devices are checked whether they comply with all technical specifications. Highly qualified metrology engineers carry out the check-up of every instrument at a specialized laboratory and with the help of master gages. If necessary, we can send you photos or video with the check-up process. I ship only fully working devices complying with all parameters. The warranty for this device is 1 year from the date of shipment from my warehouse. Within 1 year term I will provide the repair of the device for free in case of manufacturing defect or when the technical parameters do not comply with technical documentation. You will have to pay only for delivery. When a device is out of order due to your fault (its fall, it is flooded with water, the power supply does not meet the specified technical requirements, input signals exceed the norm, etc.) or there are conspicuous marks of casing opening (broken warranty labels), it is considered a non-warranty repair. Within 1 year term we can advise you for free on the device operation. After-warranty service After warranty termination I can arrange a paid repair and technical maintenance of a device as well as I can sell you all necessary spare parts for repair at minimum prices. I always have them in stock. Packaging Immediately after checking, the device will be wrapped in several layers of strong air-bubble film and placed into a strong cardboard box. Extra cardboard plates will be used for fixation. If necessary, wooden box or pallet may be used. For a more reliable fixation foam can be applied. The whole box will be placed in a waterproof polyethylene bag which will be wound with several layers of packing tape. A special handle will be made for ease of transportation. Thus, I guarantee qualitative and conscientious packing of the device that reduces to minimum the possibility of damage during transportation. Discount (from-10% to -90%) I suggest you a device which is unique in its class and price category with the following specifications: (accuracy, measurement range, error, temperature operating conditions), endurance and durability (military performance, aluminum, stainless steel, titanium or carbolite casing, shock and vibration resistance, high maintainability and reliability), free measuring kit (cables, adapters, load, fuses, etc.), 1year warranty. Unused cheap devices with the same specifications, accuracy and durability do not exist. If you consider the price for this device unreasonably high, and you know the similar equipment at a lower price, please, let me know. I will help you to compare these two models. In case your model (which is cheaper) is the same as the device I suggest or even it is better, then I guarantee to sell you a unit at that cheaper price with additional 10% discount. Shipping details: Please, mind that I ship from Ukraine (Europe, +2), so that the shipping time may differ from your local time. I send goods via AirMailpost. App. delivery time : Europe – 7-15 days; USA, Japan&others – 10-2days (depends on a country). I will ship in 2-3 business days after payment clearance. The goods may also be delivered by the express mail services such as DHL, UPS, FedEx, TNT or EMS. With express delivery you will mostly receive your goods within 3-7 working days. Payment details: I expect payment in 4 days after the auction ends. I accept a PayPal payment as the safest way of payment (preferably). If you do not have a PayPal account you can pay by wire transfer to my credit card. Other variants of payment are acceptable, for example in case of pickup way of shipping, i can accept cash payment. (This will be an official purchase on eBay). Please, tell me if you cannot pay in time, we can always negotiate it. When purchasing a few items, you’ll save on shipping. Return policy: I accept refunds and returns. If there is something wrong with the device, please, inform me within 5 days after receiving it. I will refund your costs or send you the other item, as you wish (after I receive the previous item). Please only serious bidders!

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	CCHB-74
MPN	CCHB-74
Model	CCHB-74
