Applent AT2816B TFT LCR Meter RS232C/ExHander 50Hz-200K Hz 33 Point L C R Z D Q, US $1,219.00 – Picture 0
Applent AT2816B TFT LCR Meter RS232C/ExHander 50Hz-200K Hz 33 Point L C R Z D Q, US $1,219.00 – Picture 0

Applent At2816b Tft Lcr Meter Rs232c/exhander 50hz-200k Hz 33 Point L C R Z D Q

US $1,219.00

  • Hong Kong, Hong Kong
  • Apr 27th
Open on mobile:
QR code
We ship to you about 5-8 working days, 3 years warranty, no customs taxes. 1. Descriptions   AT2816B adopts true-color TFT-LCD and English operation interface (Chinese also available). Menu softkey board operation & digital keypad.6 dgt display with the maximum speed of 30 times/second. IT can not only scan 10 groups frequency or voltage level list, but also correct 3 groups of user frequency so as to improve the accuracy.   Equipped with automatic 14-bin sorting interface and RS-232C interface.   AT2816B Digital LCR Meter SPECIFICATIONS Parameters  Cs-Rs, Cs-D, Cp-Rp, Cp-D,Lp-Rp, Lp-Q,Ls-Rs, Ls-Q, G-B, R-X, Z-?rad, Z-?deg Monitor Parameters Z, D, Q, ?r, ?d, R, X, G, B, Y, Vac, Iac, ?, ?% Accuracy 0.1% ±5 dgt   Frequency 50Hz - 200kHz (37 kinds frequency)   Display Range L: 0.00001?H-999999H             C: 0.00001pF - 999999?F R,Z:  0.00001 - 99.9999M?  D: 0.00001 - 9.99999 Q: 0.00001 - 99999.9 ?(deg): -179.999 °-179.999 ° ?(rad): -3.14159 – 3.14159 ?%: -999999% - 999999% Source Resistance 30?, 50?, 100? Range 9 ranges,  Automatic, Manual, Nominal Max Reading 6 dgt, principle parameter: 999999; sub parameter: 999999; monitor parameter: 999999 Signal Source 0.01V - 2.00V (10mV Step) Speed 30 times/second, 10 times/second, 6 times/second, 3 times/second 1-256 times average is available Comparator 14-bin sorting, 10-bin GD, 1-bin NG, 1-bin AUX, 2-bin principle parameter NG Count function: Max - 999999 List Scanning 10 groups frequency and level scanning test Adjustment Open/Short frequency reset, 3 point frequency and load correction Files 10 group files to save users' setting, 1 group to save system data real-time Interface RS232C, ExHandler Interface, with standard USB disc interface (article 10000 data) Others LCR automatic select, keypad lock, SCPI instruction set, true-color TFT-LCD display GENERAL FEATURES Power Supply Voltage: 90V AC - 250V AC Frequency: 50Hz - 60Hz Power: Max 20VA Dimension & Weight 264mm(Width)x107mm(Height)x350 mm(Depth); 4kg ORDERING INFORMATION Accessories ATL501: Test cable  ATL601: Test Fixture ATL600: Short-circuit device  ATL108: 232 Communication cable
