Hi-accuracy 0.1% Bench Lcr Meter Lcrzdq ? Deg Rad Esr Test 100khz Usb 2817b

US $545.00

Shenzhen, China
Apr 25th

Open on mobile:
QR code

U2817B Brief Introduction U2817B LCR meter is newly-developed component measurement instrument providing high performance at low cost. U2817B with its latest measurement technologies, large character LCD display, surface mount technique, easy of use and excellent appearance can be used for quality control on production line, incoming inspection of components and automatic test system. The RS-232C interface can be used to carry out remote control and statistics and analysis of measurement results. Features: 1. Economical and practical LCR meter to meet the conventional test requirement 2. Large character LCD display with backlight 3. Easy operation with strong functions 4. SMT surface mount technic 5. Fast measurement speed (20meas/sec) to meet the test system requirements 6. Comprehensive measurement parameter and stable readings 7. Selectable signal source output impedance: 30 OHM, 100 OHM 8. 5 Bins comparator 9. USB, RS-232C and HANDLER interface Specifications Measurement parameter Primary Parameter: L/C/R/Z Second Parameter: D/Q/?/X /ESR Basic Accuracy 0.1% Equivalent Circuits Serial, parallel Tolerance Mode Absolution, Percent Range Mode Auto, Hold Trigger Mode Internal, Manual, External, DUT, BUS Measurement Speed Fast: 20, Med: 10, Slow: 3 (meas/sec) Calibration function Open/Short sweep correction Measurement terminal 5-terminal Display mode Direct, ?ABS, ?% Display Large character LCD with backlight Measurement signal Signal frequency 50Hz,60Hz,100Hz,120Hz,1kHz, 10kHz,20kHz,40kHz,50kHz,100kHz Output impedance 30OHM , 100OHM Test level 0.1Vrms, 0.3Vrms, 1Vrms Measurement display range |Z|, R,X,ESR 0.0001OHM - 99.999MOHM C 0.01pF - 99999u F L 0.01µH - 99999H D 0.0001 - 9.9999 ?(Deg) -179.9° - 179.9° ?(Rad) -3.14159 - 3.14159 Q 0.0001 - 999.9 ?% -999.99% - 999.99% Comparator and interface Comparator NG, P1, P2, P3, AUX, 5 bins and alarm selectable Interface USB, RS232C, Handler Standard Accessories: U26001 4-terminal test fixture U26004 4-terminal Kelvin test cable U26010 gilded shorting plate Optional accessories: U26005 4-terminal test fixture U26006 Axial component test fixture(used with TH26005) U26008 SMD component test fixture U26009 SMD test tweezers U26011 4-terminal pair Kelvin test cable U10201 RS232C Control software Note: we'll ship this item via express mail service to USA, Canada, Australia, New Zealand, Ireland, Austria, Belgium, Denmark, Germany, France, Finland, Luxemburg, Malta, Norway, Sweden, Swiss, Spain, Italy, UK, Japan, Korea,Thailand, Malaysia, Indonesia, Philippine, Singapore. Clients from other countries pls contact with us in advance to confirm different shipping charges before you order.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	U2817B
Country/Region of Manufacture	China
MPN	U2817B
