Arduino Joystick Shield

AU $6.90

Sydney, Australia
Jun 9th

Open on mobile:
QR code

Overview The Joystick shield sits on top of your Arduino and turns it into a simple controller. 7 momentary push buttons and a two-axis thumb joystick gives your Arduino functionality on the level of old Nintendo controllers. DESCRIPTIONThe Joystick Shield kit contains all the parts you need to enable your Arduino with a joystick! The shield sits on top of your Arduino and turns it into a simple controller. Five momentary push buttons (4+ joystick select button) and a two-axis thumb joystick gives your Arduino functionality on the level of old Nintendo controllers. The momentary push buttons are connected to Arduino digital pins 2-6; when pressed they will pull the pin low (utilizing the internal pull-ups of the Arduino). Vertical movement of the joystick will produce a proportional analog voltage on analog pin 0, likewise, horizontal movement of the joystick can be tracked on analog pin 1. Electrical Characteristics Parameter Min. Typical Max. Unit Power voltage 3 5 5.5 VDC Input voltage VH (Target Voltage = 3.3V) 3 3.3 3.6 V Input voltage VH (Target Voltage = 5V) 4.5 5 5.5 V Input voltage VL -0.3 0 0.5 V Current Consumption - 20 40 mA Hardware Pins description Pin Output type Description D0 NA No Connection D1 NA No Connection D2 NA No Connection D3 Digital Button E Output D4 Digital Button D Output D5 Digital Button C Output D6 Digital Button B Output D7 Digital Button A Output D8 Digital Button F Output D9 Digital Button G Output D10 NA No Connection D11 NA No Connection D12 NA No Connection D13 NA No Connection A0 Analog Joystick Y Ouput A1 Analog Joystick X Ouput A2 NA No Connection A3 NA No Connection A4 NA No Connection A5 NA No Connection Jumper description Switch Description +3.3V Work with 3.3V system, like IFLAT32, Iteadmaple +5V Work with 5V system, like Arduino, Iteaduino Pin map description VCC B OUTPUT A OUTPUT Y OUTPUT X OUTPUT GND GND C OUTPUT D OUTPUT E OUTPUT F OUTPUT G OUTPUT Specification Version 1.0 Compatible Mainboard Leaf maple Arduino Deumlanove/UNO Arduino MEGA ChipKit MAX32 ChipKit UNO32 FEZ Panda II Freeduino Iteadmaple Iteaduino Iteaduino ADK Iteaduino BT Iteaduino MEGA 2560 Simple Cortex Seeeduino Seeduino MEGA Shield Functions Input Board Size 70mm x 54mm Operation Level Digital 3.3V Digital 5V Stackable No Model IM120417014 Accessories No Weight 50.00g Download Datasheet DS_IM120417014_ITEAD_Joystick_shield Schematic SCH_IM120417014_ITEAD_Joystick_shield

Condition:	New	Brand	IteadStudio
Model	IM120417014
