Raspberry Pi Chroma Servo Board V3

AU $31.90

  • Sydney, Australia
  • Jun 9th
Open on mobile:
QR code
Overview Chroma Servo Board for Raspberry Pi is a small board that connects to a Raspberry Pi and allows you to control up to eight RC servos (or ESCs) via the serial port in the GPIO port of the Raspberry Pi. The commands for the serial version are simple ASCII. DESCRIPTIONChroma Servo Board for Raspberry Pi is a small board that connects to a Raspberry Pi and allows you to control up to eight RC servos (or ESCs) via the serialport in the GPIO port of the Raspberry Pi. The commands for the serial version are simple ASCII. The 2x13 pin header on top is a pass through if you want to connect other cards using the GPIO-port. Of course this SW will also be open source. The serial ASCII protocol will be the same as for the HW v2 board and SW. The output is buffred and made 5V by a buffer IC. If you are into AVR-programming you can reprogram the little MCU on the RPi Servo board and make the card do whatever you like. Maybe read 6 temperature sensors and send the values as ASCII on the serial port? The card also has a 8 pin connector (unmounted) that exposes 6 GPIO-pins of the ATmega8 CPU, +3.3V and GND. With firmware version 0.2 there are experimental support to use them as as digital output controlled via a serial command. If you want to make your own firmware the pins is also the ATmega8s I2C lines (2 pins) and SPI (4 pins). Size: 39.6 mm x 35.7 mm x 18.5 mm Specification Link Wiki N/A Module Type No Weight 25.0000 Model IM140414001 Board Size 39.6 mm x 35.7 mm x 18.5 mm Version V3.0 Operation Level Digital 3.3V Digital 5V Power Supply External 3.3V External 5V
Condition: New Brand IteadStudio
Model IM140414001
