Rboard - Arduino Board With Built-in Relay

AU $27.90

  • Sydney, Australia
  • Jun 9th
Open on mobile:
QR code
Overview Arduino, relays, nRF24L01+ socket, XBee socket, micro SD socket built in, RBoard will add relay control as well as wireless connectivity to your projects. It's great for anything from home automation to robot control. The possibilities are endless! DESCRIPTIONRboard is a unique Arduino board which features 4 channels isolated relays, an XBee socket, and an ATMega328. This board will add relay control as well as wireless connectivity to your projects. It's great for anything from home automation to robot control. The possibilities are endless! Features 4 optocoupler isolated channels 4 mechanical relays with status indicator LED Both "NC" and "NO" ports for each relay ATMega328P with XBee interface headers, Micro SD socket With Arduino Duemilanove bootloader Hardware Arduino Pin Description D0 RxD D1 TxD D2 XBee Reset D3 nRF24L01+_IRQ D4 Relay 0 D5 Relay 1 D6 Relay 2 D7 Relay 3 D8 nRF24L01+_CE D9 nRF24L01+_CS D10 SD_CS D11 SPI_MOSI D12 SPI_MISO D13 SPI_SCK A0 AD0 A1 AD1 A2 AD2 A3 AD3 A4 AD4/IIC_SCL A5 AD5/IIC_SDA PWR_EXT Setting Rboard is designed for isolating industrial application with external power supply.  So when remove the jumpers on PWR_EXT, use the DC 7-20 terminal to for ATMega328 and all digital circuit power supply, and supply the 5V relay by the PWR_EXT terminal with 5V, there are 2 completely isolated power systems for  controller part and relay part. If you don't need so stringent electrical isolation, put the jumpers on PWR_EXT, then you don't need an extra power supply, the relays will supply by the DC 7-20 terminal the same as controller part - but there also the opto-isolation between the relay and controller I/Os. RBoard does not have a USB connection for sketch uploading, a USB Serial adapter is required - we recommend the Foca FT232RL breakout board. Specification Microcontroller ATMega328P Max Frequency 16MHz RAM Capacity 2K FLASH Capacity 32K External Resources Onboard SD socket Electronic Brick Interface Power Supply External 12V External 24V External 5V External 7V External 9V I/O Operation Level 3.3V Board Size 79mm X 106mm Model IM120618001 Version 1.0 Weight 80.00g Accessories No Download Datasheet DS_IM120618001_RBoard Schematic SCH_IM120618001_RBoard
Condition: New Brand IteadStudio
Model IM120618001
