Atc Timer 342b Flip-flop 24-240 Volts 1/8 Hp (hub#01c03 )

US $369.00

Aurora, Nebraska, United States
Jun 9th

Open on mobile:
QR code

ATC "FLIP FLOP" TIMER 3432B 200F 10 PX 24 - 240 VOLTS 30 VDC 10 AMP @ 125 250 VOLTS 1/8 HP @ 125 VAC COMES PACKED FROM MFG IN STYRO FOAM MOULDED WITH CARD BOARD SLIP ON COVER, NO LABEL A r Repeat cycle timer with two separately adjustable MOS dig metal timing circuits, the 342 is prewired to provide Fli flip-Flop operation of a DPDT load relay. The 342 also feat features cycle progress annunciation and multiple range adjustability for each circuit 33 PRODUCT HIGHLIGHTS LOWER INSTALLATION COSTS For repeat cycle applications, a single 342 timer does the job of two ordinary timers. Installation cost is cut by more than half; a single panel cutout is required and wiring is simplified since the 342 is prewired to perform flip-flop repeat cycle timing control. MULTIPLE RANGES REDUCE INVENTORY REQUIREMENTS The 342 incorporates six switch-selected ranges for each of its two timing circuits. A single 342 thus provides any dial-adjustable timing period between 50 ms and 10 hours for each cycle of the flip-flop operation. Thus you need stock only one timer --and only one model of that timer -- to satisfy all your needs. PROGRAMMABLE RELAY OPERATION The 342’s DPDT relay can be energized either during the first timing cycle (T1) or during the second (T2) simply by moving a push-on connector from one programming pin to another on the circuit board. Thus you can change load operation from one set of contacts to the other (N O to N C) without changing the wiring. CYCLE PROGRESS INDICATION The 342’s two pilot lights provide a unique and effective method of cycle progress indication in the minutes and hours timing ranges ... blinking at an ever-increasing rate as the cycle progresses. In the 1 and 10-second ranges, the pilot light is off before timing cycles and steady on during timing. DESIGNED FOR INDUSTRIAL SERVICE the 342, a number of features and characteristics have been incorporated to ensure a long trouble-free life expectancy, even in difficult industrial environments: transformer-isolation for high noise immunity; reliable relay rated for 100,000,000 mechanical operations; oscillator-based timing circuit for high accuracy even with changes in temperature and voltage; and a versatile mounting capability in a compact housing that is dust and

Condition	New other (see details) : A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“New, job stock, comes in mfg styro foam formed packing . un used, complete .”
