Emax Pm1806 2300kv Plastic Brushless Motor Cw/ccw 1-pair For Rc Multicopters Gi

US $20.12

Shenzhen, China
Mar 9th

Open on mobile:
QR code

EMax PM1806 2300KV Plastic Brushless Motor CW/CCW 1-Pair for RC Multicopters Description: EMax PM1806 2300KV Plastic Brushless Motor CW/CCW 1-Pair for RC Multicopters Features: - Plastic injection molding motor bells, more cost and time effective than CNC processing - Metal insert plastic injection molding, key parts are still made of metals which retains the features of metal version motors - One-piece plastic injection molding front bell and barrel, assuring concentricity - The plastic parts are made of engineering plastics, ensuring strength of the motor. According to thousands of no load test, the performance is as good as metal version motors - Same mounting pattern holes with MT sereis motors, and you can replace the MT series motors with PM motors if you want to save some cost - CW/CCW propeller adapters, holding the propellers tight Specifications: - Model: PM1806 - Recommended Excitation Voltage: < 8.4V - Threaded column torsion strength: a?¦ 5kgA f.cm - Framework: 9N12P - Weight: 19g - KV: 2300 RPM/V - No-load Current(10V): 0.7A - Stator Size: 18.2 x 6 mm - Shaft: 3 mm - Diameter: 24.9 mm - Length: 28.7 mm - No.of cells: 2S LiPo Propeller: a?¤6*4 propeller - No.of cells: 3S LiPo Propeller: a?¤5*3 (3 Blade propeller) - Motor mount or multirotor frame arm of over 1mm :usage M2*4mm mounting screws - Motor mount or multirotor frame arm of over 3mm: usage M2*6mm mounting screws - Motor mount or multirotor frame arm of over 5mm :usage M2*8mm mounting screws Package Included: - PM1806 2300KV Plastic Motor CW Thread 1pc - PM1806 2300KV Plastic Motor CCW Thread 1pc Shipping & Payment: Here Offer 100% Satifiation Service,Inlucde re-send item&refund payment; All items here offer 1 year warranty It is not my Duty for Custom Tax All items will be shipped via int'l air mail( no tracking number for items under $65), the time normally takes 7-15 business days. may be later arrivel if the item is checked by custom; We only accept paypal payment.
