Four Channel Relay Shield 5v 4 Channel Relay Shield Module For Arduino S3

US $4.74

China, China
Jun 9th

Open on mobile:
QR code

Four channel Relay Shield 5V 4 Channel Relay Shield Module for Arduino S3 Relay Shield (ie 5V Quad Relay Module) is a small current signal control power equipment commonly used electronic module, enabling high-power single-chip control devices are widely used in SCM system to make smart home project; and can be directly plugged into the Arduino compatible the use of various types of motherboards, eliminating the patch cable troubles. Module features are as follows: 1. Standard Arduino Shield interfaces and shape 2. Can continue to stack other Arduino expansion boards 3. 3 M3 screw positioning holes for easy installation 4. High Drive (5V or 3.3V) normally open contact closure 5. Onboard relay indicator (red) Special Note: When using the Arduino UNO board connected to it, because UNO USB interface is extremely high, should avoid green terminals are shorted its shell. Relay Shield Interface: (the last picture show) Relay: sky- 5V DC relay , model HJR-4102-L-5V, which Relay1 behalf of the 1st relay , the other and so on. Power Interface : 5V DC power interface Indicator: four lights are red when the relay is driven high , the corresponding indicator will light up . Relay Terminals: Terminal high-power , high-current high voltage can be connected to the device . The 1st foot ( i.e. NOx) is a normally open pin , NCx pin is normally closed , COMx is common, i.e., when the relay is not driven , NOx and COMx open between two pins , NCx and COMx connection ; When the relay (x) control signal pin is high drive relays , NOx and COMx connection open between NCx and COMx. 1PCS Shipping Policy Delivery Time We ship to worldwide, it usually takes 10-30 Business Days to delivery. Shipping address We ship to your PayPal address. Please, make sure to provide us with correct, precise, and detailed shipping Address. Send Time Items will be shipped within 1 to 3 business days upon payment received or cleared. Note If you don't receive items over 30 business days, please notify us via eBay message. Return Policy: We appreciate your business and offer an instant 7 days return policy.(7 days after receive the item). The returned item has to be in its original condition. We are able to refund your money without shipping cost. Contact us: For anything about product, price, shipping or order status, please contact us via eBay message. We love positive feedback and 5 scores DSR. We will leave it for everyone that leaves it for us. inkfrog terapeak On Aug-28-15 at 22:10:53 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
UPC	Does Not Apply
MPN	Does Not Apply
