Hc-06 Rs232 Wireless Bluetooth Rf Slave Serial 4 Pins Port Module For Arduino

US $4.88

HK, Hong Kong
Jun 9th

Open on mobile:
QR code

Home Payment Delivery details Terms of sales About us Contact us Store search Store category You may also like HC-06 RS232 Wireless Bluetooth RF Slave Serial 4 pins Port Module for Arduino Product Description Note please: 1. if you want to use the AT command, you must disconnect the Bluetooth connection, in the case led to flash settings, and can only TXD, RXD sends AT commands 2. the physical device to connect a Bluetooth module, Bluetooth module baud rate must be consistent with AT Command: Responsion AT OK AT+BAUDx OKxxxxxxxx BAUD--- Baud Rate: 1----1200bps 2----2400bps 3----4800bps 4----9600bps 5----19200bps 6----38400bps 7----57600bps 8----115200bps 9----230400bps A----460800bps B----921600bps C----1382400bps AT+NAMExxxxxx OKsetname AT+PINxxxx OKsetPIN Industrial serial port bluetooth, Drop-in replacement for wired serial connections, transparent usage. You can use it simply for a serial port replacement to establish connection between MCU and GPS, PC to your embedded project and etc. Computer and peripheral devices GPS receiver Industrial control MCU projects Default serail port setting : 9600, N, 8, 1 Pairing code : 1234 Running in slave role: Pair with BT dongle and master module Usage Coupled Mode: Two modules will establish communication automatically when powered. PC hosted mode: Pair the module with bluetooth dongle directly as virtual serial. Bluetooth protocal : Bluetooth Specification v2.0+EDR Frequency : 2.4GHz ISM band Modulation : GFSK(Gaussian Frequency Shift Keying) Emission power : <=4dBm, Class 2 Sensitivity : <=-84dBm at 0.1% BER Speed : Asynchronous: 2.1Mbps(Max) / 160 kbps, Synchronous: 1Mbps/1Mbps Security : Authentication and encryption Profiles : Bluetooth serial port CSR chip : Bluetooth v2.0 Wave band : 2.4GHz-2.8GHz, ISM Band Protocol : Bluetooth V2.0 Power Class : (+6dbm) Reception sensitivity: -85dBm Voltage : 3.3 (2.7V-4.2V) Current : Paring - 35mA, Connected - 8mA Temperature : -40~ +105 Degrees Celsius User defined Baud rate : 4800, 9600, 19200, 38400, 57600, 115200, 230400,460800,921600 ,1382400. Dimension : 26.9mm*13mm*2.2mm Pin definition : PIO8 connects with LED cathodea with 470ohm series resistor in between. LED NEGATIVE connects to ground. It is used to indicate the module state. After powered on, flashing intervals differ in different states. PIO9 is used to control LED indicating paring. It will be steady on when paring is successful. PIO11, module state switching pin. HIGH -> response to AT command; LOW or floating -> regular work status. With build-in reset circuit, reset is completed automatically after powered on. Steps to set to MASTER: Set PIO11 HIGH with a 10K resistor in between. Power on, module comes into AT Command Response Status Open HyperTerminal or other serial tool, set the baud rate 38400, 8 data bits, 1 stop bit, no parity bit, no Flow Control Via serial port, send characters "AT + ROLE = 1 r n",if successful, return "OK r n", where r n is carriage return. Set PIO11 LOW, re-power, then in Master state, automatically search for slave module and connect. Packing includes: 1 x Arduino Bluetooth Module (Slave) Serial Port Payment Delivery details Terms of sales About us Contact us Payment We only accept payment through Paypal. Please pay for your item within 4 days of the auction end time. A non-payment dispute will be regrettably opened if full payment is not received. Delivery details We ship worldwide except Italy and Brazil due to their strict customs tariff policys. All items will be shipped to buyer's ebay address. Before you pay, please make sure your address in ebay matches the address you would like us to ship to. (If you want to change the address, pls. add a note when you make the payment) Any non-received items caused by invalid address registered on PayPal are not in our full refund or replacement policy. A notification email of dispatch will be sent to buyer after item is posted. Please email us if you don't receive our email after 5 days of full payment sent. All items will be shipped within 48 hours upon receipt of payment. You should be able to receive items within 3 weeks. Email us if not receive items after 30 working after full payment sent. Terms of sales 1. Our listing price includes the value of goods,packaging cost,and export taxes,not including international import duties. 2. Import duties,taxes,and charges are not included in the item price or shipping fee. 3. The import duties are buyers' responsibility.Please check with your country's customs office determine what these additional costs will be prior to your purchase. 4. All disputes arising from the import duties will be submitted to ebay for solution. About us Any questions, pls. contact us via ebay message or email us.We will reply your message within 48 hours. If you do not receive our reply within 48 hours, pls. post a message again because sometimes our message system may block some emails. Contact us If you are satisfied with our service, pls. kindly leave us a positive feedback and give us the Detailed Seller Rating with all "5 stars" in very area. Your recognition will encourage us greatly and serve you better. Should a problem arise with your order, please contact us before leaving feedback. We strive to keep all our customers satisfy. Thanks! Your feedback is critical to our success! On Aug-28-15 at 19:14:53 PDT, seller added the following information:
