Gigatronics 1018 Signal Generator 0.05-18 Ghz

US $2,399.95

Phoenix, Arizona, United States
Mar 13th

Open on mobile:
QR code

Gigatronics 1018 Signal Generator 0.05-18 GHz Tested and Working The Gigatronics 1018 Signal Generator/Counter provides several microwave generation and measurement functions which result in making the instrument a versatile microwave test set that can replace a number of instruments in many applications. The unit is a 50MHz to 18GHz digital synthesized signal generator that provides precise, highly stable and calibrated signal output. The synthesized output has versatile pulse modulation, amplitude modulation and digital sweep with selectable limits in precise increments of 1MHz, 10MHz or 100MHz. A sweep output is provided to drive XY plotters, oscopes or other external indicating devices. Gigatronics 1018 Features: Frequency Range: 0.05 to 18 GHz Step Attenuator Low Spurious and Phase Noise ±1 dB Leveling High Resolution Pulse Modulation Amplitude Modulation Digital Sweeping Frequency Measurement: Automatic or Manual Operation Frequency or Offset Measurement High Sensitivity CW or Pulse Measurement Power Meter: Displays Output Level Measures External Level Measures Input/Output Difference Gigatronics 1018 Specifications: Frequency Characteristics Range: 0.05 to 18 GHz Resolution: 1 MHz Accuracy: Same as Time Base Time Base (Internal): 10 MHz, < 1x10-6/year Time Base (External): 10 MHz ±1x10-9 or better; 0.5 to 5 Vp-p overrides internal time base Time Base Output: Buffered 10 MHz, 1 V RMS into 50 ohms, derived from internal or external time base Spectral Purity Harmonics, Subharmonics: <-55 dBc Spurious (Nonharmonics): <-55 dBc RF Output Characteristics Output Level: +3 to -99 dBm, leveled Accuracy: ±1 dB Attenuation: 99 dB in 1dB steps; settable to 119 dB in 0.1 dB steps under remote control Level Adjustment: -5 dB to +15 dB Source Impedance: 50 ohms, nominal Sweep Operation Method: Digitally controlled continuous or step and lock Mode: Automatic recycle, single sweep or single step Increments: Selectable 1, 10 or 100 MHz Sweep Time: Variable from 10 msec to 100 sec Sweep Rate: Typically 50 MHz/msec, max Sweep Trigger Input: TTL low to initiate single sweep or single step Ramp Output: 0 to +10 V, proportional to frequency between any preset limits, any sweep mode Pen Lift Output: TTL low during retrace Pulse/Square Wave Modulation Repetition Rate: Variable, 100 Hz to 50 kHz with calibrated 1 kHz point Pulse Width: Variable, 0.1 to 10 ?sec with calibrated 1 ?sec point On/Off Ratio: >60dB Rise/Fall Times: <25 nsec Overshoot, Undershoot and Ringing: ±2 dB, max Settling Time: ±1 dB within 100 nsec Sync Output: TTL level modulation waveform External: TTL level signal, 10 Hz to 1 MHz, 0.1 ?sec min width, rising or falling edge triggering Amplitude Modulation [External] Frequency Response: 10 Hz to 5 kHz at 3 dB points referenced to 1 kHz Modulation Depth: 0 to 20 dB Input Required: 1 Vp-p for 50% modulation at 1 kHz Input Impedance: 500 ohms, AC coupled Waveform: Any Frequency Counter Measurement Characteristics Mode: CW or Pulsed RF Range: 100 MHz to 18 GHz Sensitivity: typically -30 dBm Resolution: Direct, 100 Hz; Offset, 10 Hz Time Base: Same as Frequency Synthesizer Offset Range: ±500 MHz Minimum Pulse Width (Pulsed RF Measurement): 0.5 ?sec General Specifications Display: Frequency 9 digits; Power, 3 digits Remote Interface: IEEE STD 488-1978 - All front panel controls and readouts except variable modulation rate and width Operating Temperature Range: 0 to 50? C Warm-up Time (to meet all specifications): 20 minutes, max Data Sheet: Gigatronics 1018 Data Sheet Payment: Paypal accepted. We DO NOT accept Personal Checks. Note: due to eBay's new policy, sellers can no longer ask for Cashier's Checks/Money Orders via listings or emails. Contact should be made within 3 days and payment must be received within 10 days of winning. Payment must clear before shipping. Unpaid auction wins will be forfeited after 10 days and a Non-Payer report will be filed with eBay to recover the closing fees of the auction. Shipping On This Auction: Shipping & Handling can be calculated using the shipping calculator. USA shipping with UPS (No PO Boxes). Shipping to Canada with UPS. See calculator for available options. We'll ship your order within 2 business days after confirmation of your order and verification of your payment information. Shipping address must match "bill to" address. Combined shipping is not allowed. Return Policy: This item may be returned within 14 days from the date you receive your order for refund of auction sale price. Shipping & Handling fees are non-refundable. Feedback Policy: When the customer is satisfied with a purchase and leaves positive feedback then we are more than happy to leave feedback in kind. Please contact us FIRST if there is a problem or concern.

Condition:	Seller refurbished: An item that has been restored to working order by the eBay seller or a third party not approved by the manufacturer. This means the item has been inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See the seller’s listing for full details. ...	Model	Synthesized Signal Generator
Manufacturer	Gigatronics
MPN	1018
