High-accuracy 0.1% Bench Top Lcr Meter Dqz? & Transformer Tester 100khz Th2817c

US $1,259.00

Shenzhen, China
Jan 29th

Open on mobile:
QR code

Features ? Special LCD display ? 10 typical measurement frequencies from 50Hz to 100kHz ? Built-in ±2VDC bias voltage source, extendable to -5VDC~+5VDC bias voltage or max. bias current of 50mA(only TH2817C) ? 2 selectable source impedance: 30?/100?, easy to be compatible with other LCR meters ? Measurement speed up to 20times/second ? Transformer parameter measurement function (only for TH2817C) ? Built-in 5-bin comparator ? Key lock function ? Automatic LCZ function ? 10 sets of measurement parameters saved ? Automatically recalling saved measurement parameters ? HANDLER and RS232C interfaces ? Optional GPIB (IEEE-488) interface Brief Introduction ? TH2817C LCR meter is newly-devolved component measurement instrument providing high performance at low cost. It is perfect combination of general LCR meter and high-performance LCR meter with high-accuracy. The meter provides measurement speed up to 20times/second, 10 measurement frequencies from 50Hz to 100kHz, 3 common typical test levels, 5-digit resolution, two inner- source resistance selections and strong measurement functions. So it’s suitable for measurement of quality control on production line, incoming inspection, component design and evaluation. ?With the base of our years’ experience of developing LCR meter, the meter reasonably combines easy operation and strong functions, and improves performance of 100kHz LCR meter. It is ideal instrument for incoming inspection and production line use. ?TH2817C provides HANDLER, RS232C, GPIB (Optional) interfaces, through which the meter can communicate with computer and build automatic measurement system and product test line. Convenient parameter saving and loading ?TH2817C can save 10 sets of measurement parameters, and automatically load saved parameters, which doesn’t have the trouble of repeat setting. ?TH2817C has transformer measurement function. Using special transformer test fixture, turns ratio (N, 1/N), mutual inductance (M), primary and secondary inductances (L2A, L2B), primary and secondary DC resistances (DCR, R2) can be measured without changing test cable mode. With adjustable bias voltage from -5V to +5V or DC bias current up to 150mA, the meter can conveniently measure communication transformer and choke with small power. Specifications Measurement parameter: LCR |Z|, R,X,G,B,C, L, Q,D, ?(deg),?(red) Transformer: DCR, M, N, 1/N, L2, DCR2 Basic accuracy 0.1% Equivalents circuit Series, parallel Mathematical function: Absolute value deviation, ?% Ranging mode: Auto, Hold, Manual selection Trigger mode: Internal, Manual, External, BUS Measurement speed: Fast: 20, Med: 8, Slow: 2 (times/second) (>=1kHz) Average times 1 - 99 Calibration function: Open/Short frequency point, full frequency correction Measurement terminal: 5-terminal Display mode: Direct, ?, ?% Display: 5-digit resolution, special LCD display with backlight Measurement signal Signal frequency: 10 points, 50Hz, 60Hz, 100Hz, 120Hz, 1kHz, 10kHz, 20kHz, 40kHz, 50kHz, 100kHz Output impedance: 30?, 100? Test level: 0.1Vrms, 0.3Vrms, 1Vrms DC bias source: Fixed ±2VDC, 0~±5VDC adjustable; 0~±50mA DC adjustable Measurement display range |Z|, R, X 0.0001? - 99.999M? C 0.001pF - 9999.9? F L 0.001?H - 99.999kH D 0.0001 - 9.9999 Q 0.0001 - 9999.9 ? (DEG) -179.99o - 179.99 o ? (RAD) -3.1415 - 3.1415 ?% -99.999% - 999.99% N,1/N 0.001 - 999.99 DCR 0.1m? - 199.99k? M,L2 0.001?H - 99.99kH Comparator and interface Comparator: 5 bins (3 PASS bins, 1 FAIL bin), 1 AUX bin Memory: 10 sets of inner instrument settings saved and recalled Interface: RS-232C, HANDLER, GPIB (option) General Specifications Operating temperature & Humidity 0°C - 40°C,

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	TH2817C
Country of Manufacture	China
MPN	TH2817C
Country/Region of Manufacture	China
