Precision Bench Top Lcr Meter 200khz Comparator Component Parameter Test Th2816b

US $1,359.00

Shenzhen, China
Jan 29th

Open on mobile:
QR code

Component Parameter Test Instruments and Precision LCR Meter TH2816B Brief Introduction TH2816B is a new precision LCR meter combined with years of technical experience and newest measurement technology of instrument industry. With powerful measurement functions, high performance and low cost, TH2816B have been one of the world advanced instruments, and it provides users a super value measurement resolution and experience. The meter offers stable 6 digit resolution, wide frequency range (50Hz to 200kHz), programmable signal level (0.01V to 2.0V), up to 30 meas/sec measurement rate, 9 measurement ranges, 30? or 100? constant output impedance and friendly operation interface. TH2816B can be used for incoming inspection of components, quality control of product line and high accuracy laboratory use. The optional HANDLER, GPIB, RS232C interfaces make it easy to build an automatic component test system, communicate with the computer and record the test results. Features: ? 240x64 dot-matrix graphics LCD display ? Friendly user's interface and easy operation ? TH2816B: 37 typical frequency points, 50-200kHz ? Programmable single-voltage level from 10mVrms to 2.0Vrms ? World-level stability and accuracy ? 6 digit readout resolution ? Up to 30meas/sec Measurement rate ? Precision LOAD correction function ? Selectable signal source output impedances: 30?, 100? ? Direct control function for TH1773/TH1775 DC bias source ? List sweep function for up to 4 frequencies, signal levels and DC bias levels ? Direct, ? ABS and ?% display modes ? 12 control setting files memory ? Built-in comparator, 10 Bins and bin counters (TH2816A/B) ? Test signal level monitor function ? Key lock function ? Optional Handler interface ? RS-232C and optional GPIB interfaces Specifications: Measurement function: Test parameter: |Z|, C, L, X, B, R, G, D, Q, ? Basic accuracy: 0.1% Equivalent circuit: Series and Parallel Math function: Deviation and Percent Deviation Ranging mode: Auto, Hold Trigger mode: Internal, Manual, External and Bus Measuring speed: Slow: 1.5meas/sec Med: 10meas/sec Fast: 30meas/sec Correction function: Open, Short and Load corrections M e a s u r e m e n t terminal: 5 terminals Delay time: 0—60sec , with step of 1ms List sweep: List sweep for up to 4 frequencies, signal levels and DC bias levels Display Mode: Direct, ?ABS, ?%, V/I( V/I monitor), Bin number and bin counter Display: 240x64 dot-matrix LCD display, 6-digit resolution Test signal: Signal frequency: 50Hz to 200kHz , total 37 points; 50Hz, 60Hz, 80Hz, 100Hz, 120Hz, 150Hz, 200Hz, 250Hz, 300Hz, 400Hz, 500Hz, 600Hz, 800Hz, 1kHz, 1.2kHz, 1.5kHz, 2kHz, 2.5kHz, 3kHz, 4kHz, 5kHz, 6kHz, 8kHz, 10kHz, 12kHz, 15kHz, 20kHz, 25kHz, 30kHz, 40kHz, 50kHz, 60kHz, 80kHz, 100kHz, 120kHz, 150kHz, 200kHz Output impedance: 30? , 100? Test level: 10mVrms to 2.0Vrms, 10mV steps Measurement display range: |Z|, R,X 0.00001? — 99.9999M? C 0.00001pF — 999.999mF L 0.00001?H — 9.99999kH G,B 0.00001?S — 999.999S D 0.00001 — 9.99999 Q 0.00001 — 99999.9 ?(DEG) -179.999o — 179.999o ?(RAD) -3.14159 — 3.14159 ?% -999.999% — 999.999% Comparator, memory & interface: Comparator Function: 10 Bins(BIN1 to BIN9 , OUT of bins), and additional AUX bin Memory 12 control settings memory for store/recall Optional Interface RS-232C, HANDLER, GPIB Instrument Accessories: TH26005A 4 terminal test fixture TH26011A 4 terminal Kelvin test clip leads TH26010 Gilded shorting plate Optional: TH26047 4 terminal test fixture TH26048 4 terminal test fixture TH26006 Axial component test fixture TH26007 Core inductor test fixture TH26008A SMD component test fixture TH26009B SMD Kelvin test tweezers TH26033 GPIB interface cable TH26034 RS232C interface cable TH10001 GPIB interface board TH12003 RS232C control software(TH2816A) TH12004 RS232C control software(TH2817A)

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	TH2816B
Country of Manufacture	China
MPN	TH2816B
