Industrial! Eaton Compressor 175hp 3 Phase Rotary Screw Air Compressor

US $43,233.82

Clayton, Ohio, United States
Jan 30th

Open on mobile:
QR code

Please Call Eaton Compressor At 877-283-7614 or Email Us For A Lead Time 10 Year Pump Warranty With Annual Purchase of Maintenance Kit !!!! Model PRS1750003 Description 175HP Three Phase Dual Voltage Screw SCFM @ 100 PSI MAX 145 811.9 Motor Power 175HP Motor Speed(rpm) 1750 Voltage 460/575 (Extra Charge) Start Type Y-Delta Drive Type Direct Drive Air End Model E75G Noise DB(A) 87 Outlet Connection NPT 3 1/2" Dimension: L*W*H(Inch) 68x105x78 Weight:LBS 6538 CANADIAN 380V AND 575V AVAILABLE AT ADDITIONAL $5775 $600 Feature Included - Industrial Name Brand Motor - Low RPM 1750 RPM TEFC Electric Motor - Not 3450 High Speed - This Low 1750 RPM Will Increase Bearing Life- Faster Start Up Less Power In Start Up Procedure And Makes Entire Unit Much Quieter In Running Operation - All Cast Iron Frame - This Motor Is Standard NEMA Frame That Can Be Replaced Locally If Needed After Warranty Period - It Is Not A Special Hard To Find Motor Type - UL/ CSA Approved. Name Brand Rotary Screw German Built Air Compressor Pump - This Rotary Screw Pump Has Been Made Since 1953- We Have These In Service In All 50 States Name Brand Electrical Componets - UL/CSA Approval With Approval Code Numbers - Square D/ TEL - These Can Be Purchased Locally And Not A No Name Brand - No Name Brands Can Be Hard To Find Locally $400 Feature Included - ASME Code Air/Oil Separator Tank With ASME Code Saftey Valve - Many Brands Do Not Have This Code Which Is Not Legal In Many States, Especially California $400 Feature Included - Single Bar Oil Cooler/Air Cooled After Cooler - This Makes It Easy Maintenace When Cleaning Your Coolers - Top Air exhaust Air Flow $1400 Option Included - User Friendly, Larger Metal Cabinet For Plenty Of Room When Maintenancing Machine - Not Small Compact Design - Compact Design Is Much Cheaper To Build - Compact Design Is Much Harder To Work On When Maintenacing And Will Cause Higher Maintenance Cost - With Ribbed Sound Proof Material - Ribbed Sound Proof Material Will Absorb More Sound Than A Straight Flat Insulation $800 Option Included - Online/Offline And Regulator Modulation Control - Online/Offline Is A More Expensive option Included - This Will Allow On/Offline Air Demand For Lower Duty Cycles For High Duty Cycles This Will Maintain A Constant Pressure Instead of Increasing With a 20 or 30 Pound Differential - This Will Save Huge On Electric Cost - Under High Demands Running a Constant Pressure Is Better For Energy Consumpstion - Many Units Do Not Have This, They Are Straight Online/Offline And You Do Not Get The Benefit Of This Option $1500 Option Included - Programmable Controller - UL Approved With Many Features Listed Below $1500 Option Included - Direct Driven - No Belts To Maintain
