Leadshine 3-phase Stepper Set (drive + Motor) 3nd883+863s68h 6.78n.m 1.2 Degree

US $300.00

shenzhen,Guangdong, China
Jan 29th

Open on mobile:
QR code

Leadshine 3-phase Stepper Set (Drive + Motor) 3ND883+863S68H 6.78N.m 1.2 degree 3.5A New 3ND883 Introductions: The 3ND883 is a high resolution 3-phase microstepping driver based on precision current control technology. It’s suitable for driving 3-phase hybrid stepping motors from NEMA size 17 to 34. By using the advanced pure-sinusoidal current control technology, both the noise and vibration of the stepping motor have been greatly reduced, which makes the stepping motors offer servo-like performances. Compared to the 3ND583, it has broader supply voltage range and offers more microstep resolutions, thus can be used to replace more 2-phase stepping systems directly without changing application software, offering better performances. And compared to most of the microstepping drivers in the market, both driver heating and motor heating have been reduced by 15-30%. Features: *High performance, low noise and lost cost *Low driver heating and low motor heating *Supply voltage up to 80 VDC *Output current up to 8.3A (RMS 5.9A) *Input signal TTL compatible *Automatic idle-current reduction *Suitable for 3-phase stepping motors, including 3 lead and 6 lead motors *Optically isolated differential input signals, pulse frequency up to 300 KHz *16 selectable resolutions up to 25600 steps/rev *DIP switch current setting with 8 different values *PUL/DIR & CW/CCW modes optional *Over-voltage, short-voltage, over-current and short-circuit protection *Small size for easy mounting Specifications: Parameters 3ND883 Min Typical Max Unit Output current 2.1(1.5A RMS) - 8.3 (5.9 RMS) A Supply voltage 24 68 80 VDC Logic signal current 7 10 16 mA Pulse input frequency 0 - 300 kHz Isolation resistance 500 - - Mohm Applications: Suitable for a wide range of 3-phase stepping motors from NEMA size 17 to 34. It can be used in various kinds of machines, such as X-Y tables, labeling machines, laser cutters, engraving machines, and pick-place devices, and etc. It’s extremely suitable for the applications desired with low noise, low vibration, high speed and high precision. Other hot items of this Leadshine stepper drives for above applications: ND1182 Leadshine 2-phase Classic Analog Stepper Drive ND1182 AC70-150V 0.7-8.2A New ND2282 Leadshine 2-phase Classic Analog Stepper Drive ND2282 AC80-220V 0.45-8.2A New 3ND583 Leadshine 3-phase Classic Analog Stepper Drive 3ND583 DC18-50V 2.1-8.3A New 3ND883 Leadshine 3-phase Classic Analog Stepper Drive 3ND883 DC18-80V 2.1-8.3A New 863S68H Introductions: The 863S68H three-phase stepper motor is suitable for a wide range of motion control applications. Terminated with 6 motor leads, the motor can be connected in delta connection Features: *3-phase hybrid step motor *High torque design *Standard NEMA 34 dimensions *Delta wiring *Optimized for microstepping Specifications: General Step Angle 1.2° Step Angle Accuracy +5%(full step, no load) Temperature Rise 80°CMax Ambient Temperature -10°C -- +50°C Insulation Resistance 100M?min.500VDC Dielectric Strength 500VAC for one minute Shaft Radial Play 0.06 Max.(450g-load) Shaft Axial Play 0.08 max.(450g-load) Model No. Step Angle Holding Torque Current /phase Inductance /phase Resistance /phase # of leads Rotor Inertia Detent Torque Motor Weight Motor Length L (°) N.m A mH Ohm g.cm2 N.cm Kg mm 863S22 1.2 2.0 5.0 2.8 0.9 6 1200 - 2.1 73 863S42 1.2 4.0 5.0 4.5 1.35 6 2500 - 3.0 105 863S68H 1.2 6.78 3.5 20 4.5 6 3300 - 3.8 127 Matching drives: Model Match drives 863S22 3DM683/3DM883 863S42 3DM683/3DM883 863S68H 3DM683/3DM883 Applications: Suitable for all kinds of small and medium-sized automation equipment and instruments, such as: engraving machine, marking machine, cutting machine, laser typesetting, plotter and CNC machine tools, automatic assembly equipment, etc. The efficiency is very high for the users who expect low vibration, little noise, high precision and high speed small equipments. Other hot items of this Leadshine 3-phase stepper motors for above applications: 573S05 Leadshine 3-phase Stepper Motor 573S NEMA23 Series 573S05 Step Angle 1.2 Degrees 5.2A 0.45N.M New 573S09 Leadshine 3-phase Stepper Motor 573S NEMA23 Series 573S09 Step Angle 1.2 Degrees 3.5A 0.6N.M New 573S15 Leadshine 3-phase Stepper Motor 573S NEMA23 Series 573S15 Step Angle 1.2 Degrees 5.8A 1.3N.M New 863S22 Leadshine 3-phase Stepper Motor 863S NEMA34 Series 863S22 Step Angle 1.2 Degrees 5.0A 2.0N.M New 863S42 Leadshine 3-phase Stepper Motor 863S NEMA34 Series 863S42 Step Angle 1.2 Degrees 5.0A 4.0N.M New 863S68H Leadshine 3-phase Stepper Motor 863S NEMA34 Series 863S68H Step Angle 1.2 Degrees 3.5A 6.78N.M New Contact information: Fast To Buy Ltd 1207, International E-Commerce Industrial Park of FuTian, Shangmeilin, Futian district, Shenzhen, 518049, CN Phone: +0086 13724354369 or +0086 755 82546545 email: ebay@fasttobuy.com skype: ebayfasttobuy our working time: EST 9:00AM ~ 6:00 PM Shipment: Once payment received. Item will be shipped out within 1-3 working days by DHL, Fedex, UPS, EMS ASAP. Usually it takes 3-7 working days to most of the country. You will be notified the traking number once shipped out. Kindly please note the Tax fee and Customs clearance fee are not included in the item’s listing price. Kindly please feel free to contact us before shipping if there’s any thing we can do for you. Warranty: Fast To Buy Ltd make sure the item is brand new with original package and offer 1 year warranty for the quality. Return policy: We accept return or refund within 14 days for the quality reason, not man-made reason. Kindly please contact us before returning the package. Payment will be refunded to you within 24hrs once the package received by us. You understanding appreciate. Kindly note: Pls check and confirm the part NO. and your application before place order, any further assistance please feel free to let us know. Company picture:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Leadshine
MPN	3ND883+863S68H
Model	3ND883+863S68H
