Multifunction Thermocouple Rtd Process Calibrator 2in1 Dcv Ohm Source Output

US $475.00

Shenzhen, China
Jan 29th

Open on mobile:
QR code

Note: USB function is not available. Multifunction Temperature Calibrator (referred to as “The Calibrator”) is a handheld, high capacity and rechargeable battery-operated instrument that measures and sources electrical and physical parameters. Such as measures and simulates a variety of thermocouple (TC) and Resistance Temperature Detector (RTD). See Table 1. In addition to the functions listed in Table 1, the Calibrator also has the following characteristics 1. A split-screen display. The upper display allows users to measure volts, current. The lower display allows the user to measure and source Millivolt, resistance temperature detectors, thermocouples and ohms. 2. A thermocouple (TC) input/output terminal with Cold Junction Compensation, ambient temperature can be set and calibrate within the menu function. 3. Each parameters can manual and automatic stepping and ramping output, signal output can be arbitrarily set within the 0% and 100% of the value. 4. In the configuration menu can be set manually: Power off time for Instrument, Backlight off time, Screen Contrast, Cold Junction compensation ON/OFF, HART resistance ON/OFF and etc. 5. Have calendar clock function, it can be calibrated in configuration menu. 6. It can be store 8 sets of measurement and output data and call the showing at any time, all the settings and the functions of the last operation be auto-stored after power off. 7. High capacity rechargeable battery pack with power adapter within integrated charge-management functions. 8. Novel shape and large screen dot-matrix graphic display. Table 1. Summary of Source and Measure Functions Function Measure signal Output DC Voltage (the upper display) 0.000-30.000 V DC Current (the upper display) 0.000-24.000 mA Loop power (the upper display) 0.000-24.000 mA DC Millivolt -10.000mV-80.000mV -10.000mV-80.000mV Resistance 0? to 400.00? 400.0? to 4000.0? 5.00? to 400.00? 400.0? to 4000.0? Thermocouple (TC) Type: S, R, B, K, N, E, J, T(mV) Resistance Temperature Detector (RTD) Pt100(385) Pt100(3926) Pt100(3916) Pt200(385) Pt500(385) Pt1000(385) Cu100(ITS) Cu50(ITS) Other functions Stepping output, Ramping output, Store data, a split-screen display. Technical Index: Specifications are based on a one year calibration cycle and apply from +18 °C to +28 °C unless stated otherwise. All specifications assume a five-minute warmup period. The presentation of accuracy is: ± (reading value *% + lower order digits) Temperature coefficient: -10 °C to 18 °C, +28 °C to 55 °C: ±0.005 % of range per °C 1. DC Voltage Measurement Range Resolution Accuracy 0-30.000V(upper display) 0.001V 0.02%+3 -10.000-80.000mV 0.001mV 0.01%+10 2. DC Voltage output Range Resolution Accuracy -10.000—80.000mV 0.001mV 0.01%+10 3. DC Current (Milliampere) Measurement Range resolution Accuracy 0—24.000mA(upper dispaly) 0.001mA 0.02%+4 4.Ohms Measurement Ohms Range Accuracy±? 4-wire(4W) 2-wire(2W)and 3-wire(3W) 0—400.00? 0.1? 0.15? 400.0—4000.0? 0.5? 1? Excitation Current: 0.2mA.Maximum input voltage: 30V.2-wire: Does not include lead resistance. 3-wire: Assumes matched leads with a total resistance not exceeding 100 ?. 5. Ohms Source Range Excitation Current from Measurement Device Accuracy±? Resolution 5.00? to 400.00? 0.15mA-0.5mA 0.1? 0.01? 5.00? to 400.00? 0.5mA-2mA 0.05? 0.01? 400.0 to 1500.0? 0.05mA-0.8mA 0.8? 0.1? 1500.0? to 4000.0? 0.05mA-0.4mA 1.5? 0.1? 6.Temperature ,Thermocouples Type Range Resolution Measurement and Source Accuracy±°C S -50.0°C to 0°C 0.1°C/0.1F 1.5°C 0°C to 500.0°C 0.1°C/0.1F 1°C 500.0°C to 1760.0°C 0.1°C/0.1F 0.8°C R -50.0°C to 0°C 0.1°C/0.1°F 1.5°C 0°C to 500.0°C 0.1°C/0.1°F 1°C 500.0°C to 1760.0°C 0.1°C/0.1°F 0.8°C B 200°C to 800°C 800°C to 1800°C 1°C/1°F 2.2°C 1.8°C K -200.0°C to 1370.0°C 0.1°C/0.1°F 0.8°C N -200.0°C to 1300.0°C 0.1°C/0.1°F 0.8°C E -200.0°C to 1000.0°C 0.1°C/0.1°F 0.5°C J -200.0°C to 1200.0°C 0.1°C/0.1°F 0.5°C T -200.0°C to 400.0°C 0.1°C/0.1°F 0.5°C The thermocouple complies with ITS-90. If open the cold junction compensation (CJC ON), additional plus ± 0.3 °C. 7.Temperature, Resistance Temperature Detectors (RTD) Type Range Accuracy±°C Measure 4-wire°C Measure 2-wire and 3-wire°C Output°C Pt100-385 -200.0°C-850.0°C 0.3°C 0.5°C 0.3°C Pt100-3926 -200.0°C-850.0°C 0.3°C 0.5°C 0.3°C Pt100-JIS -200.0°C-850.0°C 0.3°C 0.5°C 0.3°C Pt200-385 -200.0°C-250.0°C 0.2°C 0.3°C 0.2°C 250.0°C-630.0°C 0.8°C 1.6°C 0.8°C Pt500-385 -200.0°C-500.0°C 0.3°C 0.6°C 0.3°C 500.0°C—630.0°C 0.4°C 0.9°C 0.4°C Pt1000-385 -200.0°C-100.0°C 0.2°C 0.2°C 0.3°C 100.0°C-630.0°C 0.2°C 0.3°C 0.3°C Cu100 -50.0°C-150.0°C 0.4°C 0.6°C 0.4°C Cu50 -50.0°C-150.0°C 0.4°C 0.6°C 0.4°C Resolution: 0.1 ° C, 0.1 ° F. Allowable excitation current (Source): Pt100-385, Pt100-392, Pt100-JIS, Pt200-385: 0.15 to 3.0 mA Pt500-385: 0.05 to 0.80mA; Pt1000-385: 0.05 to 0.40mA. * 2-wire: Does not include lead resistance. *3-wire: Assumes matched leads with a total resistance not exceeding 100 ?. 8. Loop Power Voltage: 24 V; Maximum current: 22 mA ; Short circuit protected. 9. Complex Index Operating temperature -10°C to 50°C Storage temperature -20°C to 70°C Operating altitude 3000 meters above mean sea level Relative Humidity (% RH operating without condensation) 75%(30°C to 40°C) / 45%(40°C to 50°C) 35%(50°C to 55°C) / uncontrolled < 10 °C Stability ± 0.005 % of range/°C outside of 23 ± 5 °C Vibration Random, 2g, 5 to 500 Hz Safety EN 61010-1:1992 Protection Class Pollution Degree II Protection Class(L*W*H) 224mm*172mm*65mm Weight About 1.5kG(Include the battery) Accessories: a pair of Test leads, a power adapter(US, Euro, UK or AU plug), 8PCS x Ni-MH rechargeable battery 1.2V AA, a thermocouple conversion plug, Carrying case. PDF manual.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	7212
Country/Region of Manufacture	China
MPN	7212
