NEW 10' x .87" MG QUANTUM PLATE BENDER M 3022 D 4 ROLL WITH MOVABLE DIGITAL DISPLAY CONSOLE ON WHEELS MADE IN ITALY – SOLD IN THE U.S.A. Installed Power 15 HP Top Roll Diameter 13.78” Bottom Roll Diameter 13.00” Side Roll Diameters 9.84” Working Length 10.1’ Rolling Capacity .87” MILD STEEL* Pre-Bending Capacity .71” MILD STEEL* Plate Roll Dimensions 17.3’L x 5.6’W x 6’H Working Height 3.5’ Geometry Planetary Driven Rolls (Top/Bottom) 2 Drive System Directly splined on the roll shaft * CONTACT OUR OFFICE FOR FULL CAPACITY CHART The ultimate evolution in the plate bending field. Two dragging rolls with hydraulic pinching granting a steady and precise material dragging. This plate bending machine is the easiest, the most versatile, most precise, and the quickest machine the market can offer. All parts are selected among the best brands in the world to grant precision, long life and versatility. Standard equipment: - Movable Console - Hydraulic system for opening the machine and ejecting the tube. - Safety system to conform to EC Rules. - Electro welded monolithic structure normalized and machined on the new generation CNC boring machines - Exclusive integrated hydraulic system developed for height performances - Parallelism control by means of massive torsion bars to guarantee height precisions also where the newest hydraulic systems fail. - Permanent lubrication system - Planetary movement of the rolls to avoid any kind of friction and to guarantee height precision for the machine life. MOTORIZATION A 4 roll plate bending machine motorization is made of two hydraulic motors, directly assembled to the rolls by particular motion transmission gears and gear boxes that gives the maximum performances with the minimum possible strength. The motion is given to the motors trough a hydraulic pump, which is set in action by an electric motor, it is successively given to the inductors and then to the rolls. Furthermore, motorization is very important during the pre-bending phase, it allows to position the plate at the center of the rolls with the maximum precision, without losing it. This is due to the fact that we are using a 4 roll machine, and can pinch the plate with the central rolls, thus, to get a pre-bending that will not be over 1.5 or twice the plate thickness itself. PERMANENT LUBRICATION SYSTEM Thanks to the using of high quality and high resistance materials, can grant a system of permanent lubrication. By using autolubricated bearings it will be enough only to grease the parts during the assembling. Quantum plate bending machine’s maintenance won’t be a problem, only a periodical refilling of the oil will be necessary. BUILDING FEATURES - Electro-welded steel frames worked on NC working stations. - Rolls movement at variable speed from 0 to 100% (this does not include machines with electro-hydraulic controls and Lynx controlled). - High performance Hydraulic motors, with energy saving, no secondary transmissions such as chains, gears, belt ... - Immediate stopping of all moments by over center valves. - Variable speed shaping side rolls (this does not include machines with electro-hydraulic controls and Lynx controlled). - Bending rolls by massive torsion bars. - Central rolls pressure setting by hydraulic valve, this grants the right pinching for every material thickness. - Hydraulic opening system for pipes ejection. - Top roll automatic balancing (for machine opening). - Rolls mounted on high loading bearings and double row rolls. - Pinching rolls double cambering so to adapt to the natural deflection of rolls themselves during the working process, this will avoid all defects. CUSTOMER CAN ARRANGE PICK UP OR WE CAN GET A QUOTE FOR YOU ON SHIPPING SHIPPING F.O.B. MIRA LOMA, CALIFORNIA PLEASE CALL OUR SALES OFFICE IF YOU HAVE ANY QUESTIONS OR WOULD LIKE ADDITIONAL SPECIFICATIONS ON THIS UNIT 909 476 8007
