Npj-cwm1 Corner Wing Miniature Nut Plate Jig 4 Piece Set (cwm)

US $2800

  • Thousand Oaks, California, United States
  • Oct 23rd
Corner Wing Miniature Nut Plate Jig 4 Piece Set (CWM) Description Corner wing miniature nut plate jigs are designed to facilitate accurate rivet hole drilling for standard plate nuts (also known as Anchor Nuts Or Nut Plates), Omega Technologies' hand-held nut plate jigs are manufactured to precise tolerances and include drill bushings to reduce wear and assure consistent hole-spacing. Each tool features an ergonomically designed handle with a flexible stainless spring blade, allowing for clearance while the jig is in use. Corner Wing Miniature Nut Plate Jig 4 Piece Set (CWM) Includes: NPJ518SB - Equivalent Part Number AT518SB Technical Specifications: (C) Hole Spacing: 0.2180 (J) Hole Spacing: 0.308 (P) Pilot Diameter: 0.1390 (K) Drill Size: #40 NPJ518SC - Equivalent Part Number AT518SC Technical Specifications: (C) Hole Spacing: 0.234 (J) Hole Spacing: 0.331 (P) Pilot Diameter: 0.1640 (K) Drill Size: #40 NPJ518SD - Equivalent Part Number AT518SD Technical Specifications: (C) Hole Spacing: 0.250 (J) Hole Spacing: 0.354 (P) Pilot Diameter: 0.1910 (K) Drill Size: #40 NPJ518SE - Equivalent Part Number AT518SE Technical Specifications: (C) Hole Spacing: 0.281 (J) Hole Spacing: 0.397 (P) Pilot Diameter: 0.2480 (K) Drill Size: #40 Technical Specifications Number of Pieces: 4 Equivalent Part Numbers: AT518SB, AT518SC, AT518SD, AT518SE
