Ophthalmic Unit Tw-1510

US $10,699.00

United States
Jan 30th

Open on mobile:
QR code

Brand New - Ophthalmic Unit -Model TW1510 Model TW-1510 Ophthalmic Unit This unit includes: Chair and stand, Phoroptor, Standard Auto Chart projector, remote control with more than 40 charts, Trial Lens Set & Trial Frame. Specifications: TW-1510 Ophthalmic Unit Used of ophthalmic diagnosis and optometry as a general ophthalmic unit. Features: 1. Hydraulic pressure up and down movement with lower noise; 2. Able to be equipped with arm, projector and so on; 3. Economical background illumination, comfortable; 4. Reasonable construction and clipper-built shape; Specifications: 1. Arm tilting angle…………±30?; 2. Table rotate angle……………90?; 3. Table slip scope………±150mm; 4. Chair rotate………………±60?; 5. Chair height…………500-700mm; 6. Weight………………200Kgs; 7. Power: 120W, 220V, 50Hz/110V, 60Hz; 8. Illumination bulb……………15W; Phoropter/Specifications: 1. Sphere Power: Range:+16.75 to -19.00 diopters; Step: 0.25 diopters 2. Cylinder Power: Range: 0.00 to -6.00 diopters (0.00 to -8.00 diopters with additional lens of -2.00 diopters); Step: 0.25 diopters 3. Cylinder axis: 0 to 180, 5° step; 4. Cross Cylinder: ±25 diopters; 5. Rotary Prisms: 0? to 20?, 1? step; 6. Auxiliary lens dial: (O)-Open aperture (two positions)(R)-Retinoscopic lens,+1.50D (P)-Polarizing lens 45°- left eye 135°- right eye (WMV)or(RMV)-Maddox rod. Vertical white-left eye red-right eye (WMH)or(RMH)-Maddox rod. horizontal white-left eye red-right eye (RL)-Red lens(1.12-10.12D sphere(PH)-Pin hole (10?L) or (6?U) -10?base-in-left eye 6?base-up-right eye (dissociating prisms) (±.50)- ±0.50 fixed cross cylinder(0C)-Occluder 7. P.D. adjustment: 48-75mm, 1mm as a step; 8. Standard Accessory lenses: Two 12D and -2.00 cylinder lenses,two plano lenses for sealing front opening; 9. Standard Accessories: 1 near point card with holder and reading rod,dust cover, face shield, accessory case for lenses; 10. Dimensions: 318 x 293 x 96 (mm); 11. Net weight: Approx 5kg. Brand New Product. The TRIAL LENS SET with 266 pieces is suitable for examining refractive errors. This aluminum case with combination lock consists of trial glass lenses mounted in metal rims (the entire inner lens tray is removable), fiber cloth, handbook and a FREE standard trial frame. Power ranges: Lens powers are clearly imprinted on each lens rim as well as on the inner tray. Speherical Convex(+) & Concave (-) Lens: ±0.25, ±0.50, ±0.75, ±1.00, ±1.25, ±1.50, ±1.75, ±2.00, ±2.25, ±2.50, ±2.75, ±3.00, ±3.25, ±3.50, ±3.75, ±4.00, ±4.25, ±4.50, ±4.75, ±5.00, ±5.25, ±5.50, ±5.75, ±6.00, ±6.50, ±7.00, ±7.50, ±8.00, ±8.50, ±9.00, ±9.50, ±10.00, ±11.00, ±12.00, ±13.00, ±14.00, ±15.00, ±16.00, ±18.00, ±20.00 Cylindrical Convex (+) & Concave (-) lens: ±0.25, ±0.50, ±0.75, ±1.00, ±1.25, ±1.50, ±1.75, ±2.00, ±2.25, ±2.50, ±2.75, ±3.00, ±3.25, ±3.50, ±3.75, ±4.00, ±4.50, ±5.00, ±5.50, ±6.00 Prism Lens: 0.5x2, 1.0x1, 2.0x1, 3.0x1, 4.0x1, 5.0x1, 6.0x1, 8.0x1, 10.0x1 Plus Auxiliary lenses (includes 2 Cross Cylinder). AVAILABILITY: 8-10 weeks
