Ophthalmic Unit Tw-1513b

US $8,300.00

Placentia, California, United States
Jan 30th

Open on mobile:
QR code

Brand New - Ophthalmic Unit -Model TW1513B Model TW-1513B Ophthalmic Unit This unit includes: Chair and stand, Phoropter, and 1 Set of Trial Lens Set of 158 pcs. Chair/TableSpecifications: Table Size.....................480x800mm Table rotate angle.........90° Illumination......................36W110V/220V Input voltage.................... Electric Chair: Height adjustment 580~730mm; Maximun weight on chair 253lb.; Power 190W; with foot switch and back switch Phoropter/Specifications: 1. Sphere Power: Range:+16.75 to -19.00 diopters; Step: 0.25 diopters 2. Cylinder Power: Range: 0.00 to -6.00 diopters (0.00 to -8.00 diopters with additional lens of -2.00 diopters); Step: 0.25 diopters 3. Cylinder axis: 0 to 180, 5° step; 4. Cross Cylinder: ±25 diopters; 5. Rotary Prisms: 0? to 20?, 1? step; 6. Auxiliary lens dial: (O)-Open aperture (two positions)(R)-Retinoscopic lens,+1.50D (P)-Polarizing lens 45°- left eye 135°- right eye (WMV)or(RMV)-Maddox rod. Vertical white-left eye red-right eye (WMH)or(RMH)-Maddox rod. horizontal white-left eye red-right eye (RL)-Red lens(1.12-10.12D sphere(PH)-Pin hole (10?L) or (6?U) -10?base-in-left eye 6?base-up-right eye (dissociating prisms) (±.50)- ±0.50 fixed cross cylinder(0C)-Occluder 7. P.D. adjustment: 48-75mm, 1mm as a step; 8. Standard Accessory lenses: Two 12D and -2.00 cylinder lenses,two plano lenses for sealing front opening; 9. Standard Accessories: 1 near point card with holder and reading rod,dust cover, face shield, accessory case for lenses; 10. Dimensions: 318 x 293 x 96 (mm); 11. Net weight: Approx 5kg. The TRIAL LENS SET with 158 pieces is suitable for examining refractive errors. This aluminum case with combination lock consists of trial glass lenses mounted in metal rims (the entire inner lens tray is removable), fiber cloth, handbook and a FREE standard trial frame. Power ranges: Lens powers are clearly imprinted on each lens rim as well as on the inner tray. Speherical Convex(+) & Concave (-) Lens: ±0.25, ±0.50, ±0.75, ±1.00, ±1.25, ±1.50, ±1.75, ±2.00, ±2.25, ±2.50, ±2.75, ±3.00, ±3.25, ±3.50, ±3.75, ±4.00, ±4.50, ±5.00, ±6.00, ±7.00, ±8.00, ±9.00, ±10.00, ±11.00, ±12.00 Cylindrical Convex (+) & Concave (-) lens: ±0.25, ±0.50, ±0.75, ±1.00, ±1.25, ±1.50, ±1.75, ±2.00, ±2.50, ±3.00, ±3.50, ±4.00, Prism Lens: 0.50x1, 1.0x1, 2.0x1 Plus Auxiliary lenses (includes 1 Cross Cylinder). Availability 8-12 weeks ( Chair and trial lens set available within 3 days)
