Pfxgp4301tadw Hmi 5.7" 320*240 Dc24v With Ethernet Dhl Freeshipping

US $760.00

shenzhen,Guangdong, China
Jan 29th

Open on mobile:
QR code

PFXGP4301TADW HMI 5.7" 320*240 DC24V with Ethernet New PFXGP4301TADW specifications: Model PFXGP4301TADW Display Type TFT Color LCD Display Size 5.7" Resolution 320 x 240 pixels (QVGA) Effective Display Area W115.2 x H86.4 mm [W4.54 x H3.40 in.] Display Colors 65,536 Colors (No blink)/16,384 Colors (Blink) Backlight White LED (User non replaceable parts. When replacement is required, contact your local distributor.) Brightness Control 8 Levels (Adjusted with the touch panel ot the software) Backlight Service Life 50,000 hrs. or more (continuous operation at 25centigrade degree before backlight brightness decreases to 50%) Language Fonts Japanese: 6,962 (JIS Standards 1 & 2) (including 607 non-kanji characters) ANK: 158 (Korean fonts, Simplified Chinese and Traditional Chinese fonts are downloadable.) Character Sizes Standard font: 8 x 8, 8 x 16, 16 x 16 and 32 x 32 pixel fonts, Stroke font: 6 to 127 pixel fonts, Image font: 8 to 72 pixel fonts Font Sizes Standard font: Width can be expanded up to 8 times. Height can be expanded up to 8 times. 8 x 16 dots 40 char. x 15 rows 16 x 16 dots 20 char. x 15 rows 32 x 32 dots 10 char. x 7 rows 8 x 8 dots 40 char. x 30 rows Program Area FLASH EPROM 132 KB (Equivalent to 15,000 steps)*1 Variable Area None Application Memory FLASH EPROM 8 MB (including a logic program area) Data Backup SRAM 128 KB (Rechargeable Lithium battery for backup memory) Clock Accuracy ±65 sec/month (deviation at room temperature and power is OFF)*2 Touch Panel Type Resistive Film (analog) Touch Panel Resolution 1,024 x 1,024 Touch Panel Service Life 1,000,000 times or more Serial (COM1) RS-232C Asynchronous Transmission Data Length: 7 or 8 bits, Parity: none, Odd or Even, Stop Bit: 1 or 2 bits, Data Transmission Speed: 2,400 bps to 115.2 kbps, Connector: D-Sub9 (plug) Serial (COM2) RS-422/485 Asynchronous Transmission Data Length: 7 or 8 bits, Parity: none, Even or Odd Stop Bit: 1 or 2 bits, Data Transmission Speed: 2,400 bps to 115.2 kbps, 187.5kbps (MPI) Connector: D-Sub9 (plug) Ethernet (LAN) IEEE802.3i/IEEE802.3u, 10BASE-T/100BASE-TX Connector: Modular jack (RJ-45) x 1 USB (TYPE-A) Conforms to USB2.0 (TYPE-A) x 1, Power Supply Voltage: DC 5 V ±5 %, Output Current: 500 mA or less, Communication Distance: 5 m [16.4ft.] or less USB (mini-B) Conforms to USB2.0 (mini-B) x 1, Communication Distance: 5 m [16.4ft.] or less SD Card None General specifications: Model PFXGP4301TADW Rated Input Voltage DC 24V Input Voltage Limits DC 19.2 to 28.8V Allowable Voltage Drop 5 ms or less Power Consumption 10.5 W or less In-Rush Current 30 A or less Voltage Endurance AC 1,000 V, 20 mA for 1 min (between charging and FG terminals) Insulation Resistance DC 500 V, 10 Mohm or more (between charging and FG terminals) Surrounding Air Temperature 0 to 50 centigrade degree Storage Temperature -20 to 60 centigrade degree Ambient Humidity 10 to 90 % RH (Wet bulb temperature: 39 centigrade degree or less ( no condensation.) Storage Humidity 10 to 90 % RH (Wet bulb temperature: 39 centigrade degree or less (no condensation.) Dust 0.1 mg/m? (10<sup>-7</sup> oz/ft?) or less (non-conductive levels) Pollution Degree For use in Pollution Degree 2 environment Atmosphere Free of corrosive gases Air Pressure (altitude range) 800 to 1,114 hPa (2,000 m [6,561ft.] above sea level or less) Vibration Resistance IEC/EN61131-2 compliant, 5 to 9 Hz Single amplitude 3.5 mm [0.14 in.], 9 to 150 Hz Fixed acceleration: 9.8 m/s?, X, Y, Z directions for 10 cycles (approx. 100 min) Concussion Resistance IEC/EN61131-2 compliant 147 m/s?, X, Y, Z directions for 3 times Noise Immunity Noise Voltage: 1,000 Vp-p, Pulse Duration: 1 µs, Rise Time: 1 ns (via noise simulator) Electrostatic Discharge Immunity Contact Discharge Method: 6 kV (IEC/EN61000-4-2 Level 3) Grounding Functional grounding: Grounding resistance of 100Mohm, 2mm? (AWG 14) or thicker wire, or your country's applicable standard. (Same for FG and SG terminals) Structure IP65f NEMA #250 TYPE 4X/13 (on the front panel when properly installed in an enclosure)*3 Cooling Method Natural air circulation Weight Approx. 0.8 kg [1.8 lb] or less (display unit only) External Dimensions W169.5 x H137 x D59.5 mm [W6.67 x H5.39 x D2.34 in.] Panel Cut Dimensions W156 x H123.5 mm [W6.14 x H4.86 in.], Panel thickness area: 1.6 to 5 mm [0.06 to 0.2 in.]*4

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	PFXGP4301TADW
MPN	PFXGP4301TADW
