Portable Digital Oscilloscope!!!!! Sampling 20m Arduino Atmega64 Programmer 2in1

US $64.59

??, China
Jan 29th

Open on mobile:
QR code

Description & Gallery Please Contact US for large amount of products or any other products we haven't listed here. For buyers from those countries we don't ship to in this listing, please contact us for solution. Introduction: Portable Digital Oscilloscope!!!!! sampling 20M Arduino ATmega64 programmer 2in1 #380101 1. introduction: this OSC is easy to handle, and it can serve in voice singal and switch power singal, even certain video singal observation fields. this OSC is more than a single-function OSC, it can work as a ATmega64 program board. you can download the code to the item via the serial port(no need programmer unit) to test and develop. then you just need to download the OSC code to get the OSC function back. Power supply voltage: DC 9~12V, please use the DC 9V power Power supply current: <250mA Display: 128 x64 LCD LCD backlight: Yes output Test signal: 500Hz/5Vpp, square wave signal. input Signal for test: input the signal via the probe Magnification options: select the magnification. Attenuation options: attenuation ratio. Coupling options: choose the the coupling manner and frequency meter switch. Weight: 130g Size: 105* 65* 25mm 2. specifications: Number of channels Single channel The input impedance 1MΩ The maximum input voltage 50 VPP (using 1 x probes) 500 VPP (using 10 x probe) The coupling way DC/AC The highest equivalent sampling rate 20MSa/s The highest real-time sampling rate 2Msps Accuracy 8Bit Sampling buffer depth 256 bytes Analog bandwidth 0 - 1MHz Vertical sensitivity 100mv/Div-5 v/Div (according to the 1-2-5progressive way) Vertical displacement Adjustable and with instructions Horizontal time base range 0.2mus/Div-10m(minutes)/Div (according to the 1-2-5progressive way) Horizontal position Adjustable and with instructions Trigger mode Auto,Normal,Single Trigger source Internal trigger and external trigger Trigger edge Rising edge and falling edge Trigger level Position is adjustable, with instructions Trigger position 1/4 (fixed) Freeze waveform Have Test signal Have, With 500 hz / 5 VPP square wave signal Stored waveform Can store and display 6 groups of the waveform Waveform to upload Can be uploaded to a PC via a serial port to waveform Frequency meter measuring range 5MHz Frequency meter sensitivity 3 v (TTL level) FFT transform length 256 points, 512 points FFT transform frequency 1KSa/s – 2MSa/s Other Function Have a trigger output, can be concatenated together with Many oscilloscopes to realize the multi-channel measurement, or other instruments used for synchronization. Observable triggered before the waveform (negative delay) 3. package list: 1pc OSC 20M 1pc normal probe leaving a Positive feedback and all 5 scors will be highly appreciated! that is great support to us! please Contact us if you do not receive the item or there is any other problem. thanks 1.Payment We accept Paypal, for other payments please contact us We ship to the shown address on you PAYPAL Payment,Please confirm your shipping address in the PayPal Account. We provide big discount for wholesale order, we are stable supplier. please contact us for details. The buyer in charge of the TAX on imports. 2.Handling and shipping We will ship the order out in 1-3days after payment. The shipping takes 10-45 business days to worldwide. We also provide DHL EMS FedEX and other express delivery, contact us for price. Please contact us if the item does not arrive in 45 days, we reply in 48 hours. 3. Return & Exchange We accept exchange or return. please contact us for returning address. 2 days money back after we receive the return item. Buyer pays for shipping back fee. 4.Contact us Please contact us via ebay message box or service email. We will respond within 2 working days. Service will be online on 12:00-22:00 from Mon. to Fri., except public holidays. Online service available.contact us for skype ID. 5.Feedbacks We appreciate your positive feedback and 5 scores for our shipping and other performance Contact us before you leave Neutral/Negative feedback. we are serious seller and we will solve any of the problem and make you 100% satisfied. 6.welcome to shop! Thanks for your order! Engineered for professional eBay sellers!
