Press Brake Tooling

US $155.99

Omaha, Nebraska, United States
Jan 30th

Open on mobile:
QR code

Have you ever had to hold a square to a press brake die to get a square bend line ??? What about create a bolt on angle attachment from shop supplies for parts with rounded edges ??? If so Brock Fab Tools has the solution for you ---This listing is for a Press Brake Magnetic Squaring Arm with Angle Gauge. Attaches magnetically for instant set-up Simultaneous instant repeatability. --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- >>>>PLEASE NOTE: THIS FITS MACHINE tooling WITH A HEIGHT OF 3.00" and larger.<<<< Please check for fitment to your tooling prior to purchase. --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- This is a listing for a tool that every press brake operator should have available for their use. This tool eliminates the need for a press brake operator bolting on back-stop square edges, or creating angles for parts with tapers, as well as rounded edges. Picture a gusset which is we what we know of as a triangular shape. We have this gusset (triangular shaped part), and we want to put straight bend across one side of that triangle. Do it repeatedly, accurate, and ensure the parts remain consistent to tolerances. To do this the operator would be required to build a bolt on tapered edge. THIS TOOL ELIMINATES THE NEED FOR BOLTING TO THE MACHINE, AND LITERALLY CAN BE SET-UP IN UNDER 60 SECONDS. The machine operator can spend 20 or more minutes creating a bolt on square edge from shop supplies. As a press brake operator sometimes I did 2 times a day !!! I created this squaring arm for my own use. And for years it has been popular with metal fabrication shops. Even though my competition sells these for over 400 a piece right here on EBAY I choose to keep my prices low. Sell what you need, and not entice you with what you don't. The Brock Fab Tool is interchangeable as a left and right hand. So that means your Company may choose to buy 1 or buy more than 1 depending upon how many machines they would need accommodate. It is an excellent choice for every production press brake. Machines used to manufacture parts efficiently where you don't want operators scrambling for nuts and bolts to put something together all because they have 100 parts alike that don't have a square edge. If you time the machine at 12-18 seconds per bend the math on that real world is 20 seconds per bend which is equivalent to 3 bends per minute. A job like this may require 30 or more minutes not factoring in the set-up time for back-stops and depth the machine bends at consistently. I know every minute counts. I also know I was not given 20 minutes to create bolt on squaring arms. Setting the angle for a gusset-like part required fine tuning the bolt to machine type. The Brock Fab Tool Squares to the die face. The Brock Fab Tool is a 2 in 1 solution. Through competitors you are forced to purchase a left as well as a right for full use of the angle gauge attachment. This tool is dual guided to accommodate both left and right hand angle gauge use. Dual guide Press Brake Magnetic Squaring Arm with Angle Gauge. Magnetic Attachment for instant set-up. Please note...Shipping is Free but only within the U.S. The handling time is 3 business days. This press brake magnetic squaring arm includes a 5/32 allen wrench, and ships assembled generally for right-hand. (Note: Some additional squaring to the die face is advised) and is a simple procedure for set-up to use as left or right. If you would prefer unboxing The Press Brake Magnetic Arm assembled for left-hand please contact Brock Fab Tools 24 hours prior shipment. All parts are painted mild steel. This accessory tool does have the ability to return its investment withen its first use. Magnetic Attachment to Press Brake Bottom 3.00" height and larger. Please check your tooling for fitment prior to purchase.
