Professional High Precision Dc Resistance Meter Micro Ohm Meter Tester

US $1,458.00

China, China
Jun 9th

Open on mobile:
QR code

Professional High Precision DC Resistance Meter Micro Ohm Meter tester Description AT515 is the pioneer of a high precision resistance meter, which is used to test super low or low resistance, it adopts high-performance ARM micro processor control. 3.5 inches true-color LCD display screen with Chinese and English menu. AT515 has accuracy of 0.01% and resolution 0.1??, 0.1?? - 1.2G1? measurement range. Excellent repeat measurement, break through the resistance value display of 6.5dgts, has 1,200,000 reading, maximum sampling rate is 4.5ms. Instrument has built-in temperature compensation interface to compensate the error caused by temperature. Instrument has built-in 14 bins of comparator output, can setup 10 GD bins, and all bins comparator results can be output by Handler interface. Instrument has RS-232 interface, adopts SCPI to communicate with PC, PLC or WINCE equipment, in order to efficiently realize remote control and data acquisition function. It is applied in measuring low resistance, shunt and contact resistance with high speed test. Specification Parameter DC resistance Accuracy 0.01% Measurement Range 0.1??~1G? Measurement current Current range: 1?A~1A Range Automatic and manual with 11 ranges Speed 167 times/second, 30 times/second, 10 times/second, 2 times/second Display Show, ?ABS??% and sorting result Display Max 1,200,000 Adjustment Open & short reset for each range Comparator 14 groups record, NG-LO, GD-IN, NG-HI display and output, adjustable beep and volume Trigger Internal, manual, external and remote Interface RS232C, Handler interface (PLC interface) Temperature compensation Accuracy: 0.2 °C Range: 0~80 °C Method 4 terminal shielding(2 check terminal and 2 driving terminal) and external shielding ground section Voltage: 198V AC - 240V AC Frequency: 50/60Hz Power: Max 15VA External size: 264mm (Width)x107mm (Height)x350mm (Depth) Inside size: 216mm (Width)x88mm (Height)x323mm (Depth) 4kg ATL501: Kelvin clip ATL108: 232 communication cable ATL620: meter resistance 4-terminal clamp fixture LCD display, switchable in Chinese and English menu Feature ? Temperature compensation function ? High current (open circuit

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	AB
Accuracy	0.01%
Model	AT515
Measurement Range	0.1??~1G?
MPN	Does not apply
Display Max	1,200,000
Country of Manufacture	China
UPC	Does not apply
