Se Inspector+ Handheld Digital Radiation Alert Detector For Low Level Radiation

US $389

Davidson, North Carolina, United States
Jun 9th

Open on mobile:
QR code

****This unit was used a handful of times for a small project. Excellent condition and like new in every way. Inspector Handheld Digital Radiation Alert Detector by SE International The Inspector is a small, handheld, microprocessor-based instrument which offers excellent sensitivity to low levels of alpha, beta, gamma, and x-rays. The digital readout is displayed with a red count light and a beeper sounds with each count detected. Other features include an adjustable timer, external calibration controls and adjustable alert. Comes with original box with carrying case with metal belt clip, and manual. Insurance and Delivery Signature included in shipping. Detector Internal Halogen-quenched, uncompensated GM tube with thin mica window, 1.4-2.0 mg/cm2 areal density. Effective diameter of window is 45 mm (1.75 in.). Radiation symbol on front label marks the center of the detector. Display 4 digit liquid crystal display with indicators. Averaging Periods Display will update every 3 seconds. At low background levels, the update is the moving average for the past 30-second time period. The timed period for the moving average decreases as the radiation level increases Energy Sensitivity Detects Alpha down to 2 MeV.Detects Beta down to .16 MeV; typical detection efficiency at 1 MeV is approx. 25%. Detects Gamma down to 10 KeV through the end window. 3340 CPM/mR/hr (Cs137). Smallest detectable level for I125 is .02 µCi at contact. Operating Range mR/hr - .001 (1µR) to 100 CPM - 0 to 350,000 µSv/hr - .01 to 1000 CPS - 0 to 5000 Total/ Timer - 1 to 9,999,000 counts Accuracy mR/hr ±10% typical (NIST), ±15% max - 0 to 100 µSv/hr ±10% typical (NIST), ±15% max - .01 - 1000 CPM ±10% typical (NIST), ±15% max - 0 to 350,000 (Referenced to Cs-137) Alert Set Range mR/hr .001 - 50 and CPM 1 - 160,000. 70db @ 1m. Count Light Red LED flashes with each radiation event. Audio Indicator Internally mounted beeper (can be switched off for silent operation) Outputs Dual miniature jack drives CMOS or TTL devices: count to computer or datalogger. Submini jack input allows for electronic calibration Anti-Saturation Meter will hold at full scale in fields as high as 100 times the maximum reading. Power Requirements One 9-volt alkaline battery. Battery life is approx. 2160 hours at normal background. Temperature Range -10?C to 50?C (14?F to 122?F) Weight Inspector: 273 grams (9.6 oz.) without battery. Size 150 x 80 x 30 mm (5.9 x 3.1 x 1.2 in.). Includes Carrying Case,
