Tektronix Tds 644a Color Digital Oscilloscope 500mhz 2gs/s +preventative Recap

US $1,549.99

Lake Forest, California, United States
Jan 29th

Open on mobile:
QR code

Working perfectly. Guaranteed by 6 months right of return, and 1 year repair/exchange warranty while I still have a backup unit. Note: TDS 644A is basically the faster sampling rate (2GS/s) version of TDS 544A (1GS/s) Passes all self-tests (including Signal Path Compensation, SPC). Comes with these options: Option 13: RS-232/Centronics Hardcopy Interface With this option, Tektronix ships the oscilloscope equipped with a RS-232 and a Centronics interface that can be used to obtain hardcopies of the oscilloscope screen Option 1F: File System (Floppy) With this option, Tektronix ships the digitizing oscilloscope with a floppy disk drive and a variety of features for managing the floppy disk. With the file system you can save and recall setups, waveforms, and hardcopies on a floppy disk. Option 2F: Advanced DSP Math With this option, the oscilloscope can compute and display three advanced math waveforms: integral of a waveform, differential of a waveform, and an FFT (Fast Fourier Transform, Spectrum Analyzer) of a waveform. This has built-in GPIB interface for communication to computer. This unit has a color screen and connects to color monitors through VGA port. ----------------------------------------------------------------------------------------------- TDS 400, 500, 600 often have electrolytic capacitors leaked at this age. Regardless of whether they function well and pass the tests, they must be recapped and washed or it's a ticking timebomb. Once you see Acq++ fail, chances are the electrolyte has eaten into the board traces and it's gone for good. All SMD electrolytic capacitors on Acq and main board and washed, recapped and rewashed throughly, You can return in 6 months for ANY REASON as long as you pay for shipping both ways. If it fails with a year of purchase, I can have it repaired or replace it for free and will pay for all associated shipping costs. If I cannot fix it, I'll gladly refund. Tektronix TDS644A Specs: (copied from http://www.jbtech.de/measuring/tektronix/tds644a.html) - 500 MHz bandwidth - Sample rates to 2 GS/s on four channels - 4 input channels - Pulse width, 1 ns glitch; - 1 mV/div -10 V/div sensitivity - Infinite and variable persistence - Color Grading - Record lengths to 15,000 points - 8-bit vertical resolution - High resolution color monitor - 3.5 inch DOS floppy disk drive - Vertical accuracy to 1.5% - Tek TriStarTM (DSP) processor - Slew Rate and Setup & Hold Violation - Waveform pass/fail testing - 25 automatic measurements - Full GPIB programmability - Desktop publishing outputs - 1.5 GHz, 1 pF, 1 Megohm probe option - Segmentable acquisition memory - VGA output Manual (620A, 640A, 644A are the same series): http://ctf3-tbts.web.cern.ch/ctf3-tbts/instr/Tektronix/TDS640A/TDS640A_Manual_EN.pdf The oscilloscope is heavy. Feel free to pick it up with cash at Irvine or Lake Forest, CA. Call 650-804-5024 if you have questions about the oscilloscope. No S&H for local pick ups with cash. The price is negotiable by 10% if you can save me the equivalent amount in terms of transaction fees. e.g. I have an equivalent post in eCrater at a lower price (at least $100 cheaper than listed. ). Please search for the auction title "Tektronix TDS 644A Color Digital Oscilloscope 500Mhz" in eCrater.com.

Condition:	Seller refurbished: An item that has been restored to working order by the eBay seller or a third party not approved by the manufacturer. This means the item has been inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See the seller’s listing for full details. ...	Model	TDS644A
Sample Rate	2GSa/s - 2.9GSa/s
Type	Digital
Make	Tektronix
Bandwidth	500MHz - 699 MHz
Number of Channels	4
Channels	4
