Tektronix Tds540 4-channel Digital Oscilloscope 500mhz 1gs/s - Needs Repair

US $250.00

  • Palm Harbor, Florida, United States
  • Jan 29th
Open on mobile:
QR code
This is a used Tektronix TDS 540 4-channel Digital Oscilloscope 500Mhz / 1 GS/s.  Cold power on shows failed self test: FAIL ++ Processor FAIL ++ Acq/Proc Interface FAIL ++ Aquisition See image 2 After running self test in manual mode the scope shows: FAIL ++ Cal Initialization See image 4  Also scope failed SPC test with Compensation Error. See image 5. However channels 1 and 2 seem to be working fine. See image 6. Channel 3 and 4 work incorrectly. Scope needs some repair! Cosmetics: The front panel has no scratches. As shown in the images, some minor scratches and marks on the case. Missing the side handle. This Auction ONLY Includes the Item Described in the Title. Sorry No manuals. This item will be well packaged. Make an Offer! Unit is sold AS-IS no return, no warranty.
Condition:
For parts or not working: An item that does not function as intended and is not fully operational. This includes items that are defective in ways that render them difficult to use, items that require service or repair, or items missing essential components. See the seller’s listing for full details. ...
Brand Tektronix
Bandwidth 500 MHz
Type Digital
Model TDS540
Channels 4 Channel
Sample Rate 1 GSa/s
